27
02/02
ENGINE CONTROL
1
23
4
5
1. THROTTLE SWITCH - Control the speed of the Engine
2. CHOKE -See Engine Operating Manual for use.
3. KEY SWITCH - Use to start Engine.
4. AUTOFEED SWITCH -
This button willactivate the AUTOFEED SYSTEM.
5. TACHOMETER\SPEED SWITCH - The tachometer measures the revolutions
per minute of the power unit.
(Typical Control Panel)
Actual controls are determined by engine type and model.
Please check the Engine Operator Manual supplied with your machine.
