Pre Start Inspection and Operation
3.3
Make sure to securely reinstall the dipstick into the dipstick tube before starting the
engine.
3. The Boxer has two saddle fuel tanks (Item 1, Figure 3–3). Each of the tanks has a
fuel gauge located in the ller cap (Item 2, Figure 3–3). Remove cap and visually
inspect fuel level to make sure that the indicator is showing the proper fuel level.
Make sure that each tank has been lled on a daily basis.
Figure 3-3 Fuel Level Check
• Carefully pour the fuel into the tank, not exceeding the max ll on the fuel gauges.
• Allow engine to cool before lling fuel tanks.
• Do not overll, fuel could spill onto hot engine parts and ignite or explode.
4. Check engine coolant level.
The coolant is hot and under pressure. DO NOT check until the engine radiator is cool
to the touch.
• Remove radiator cap (Item 1, Figure 3–4) and check the radiator uid level. The proper
coolant level will be to the bottom of ller neck.
1
E
F
2
