Table 2: Parts List for Hand Pump (39-59) - Refer to Figure 25
Item Part No. Nomenclature
Quantity
39 10-90002 Relief Valve O-Ring (T-175) 1
40 10-90004 Valve Rod O-Ring (T-155) 1
41 T-115 Valve Rod 1
42 10-90005 O-Ring (T-151) 2
43 T-111 Relief Valve Seat 1
45 10-90010 Reservoir O-Ring (T-156) 2
46 T-130 Reservoir Stud 1
47 P-17-29 Inlet Tube 1
48 P-17-7 Inlet Tube Fitting 1
49 T-250 Inlet Tube Nipple 1
50 T-408 Body Plate 1
51 10-90012 Cylinder O-Ring (T-164) 1
52 T-106 Piston 1
53 CV2SS2 Special Adapter 1
54 10-90018 Piston Back-Up Ring (T-159) 1
55 T-107 Guide Rod 1
56 01-90003 Body Attaching Screw 3
57 IGT-10 Retaining Plug 1
58 IGT-34 Vernier Piston 1
59 10-90000 Seal Ring Piston 1
