2.1 General
The Morehouse Universal Calibrang Machine is comprised of three principal assemblies:
2.3 - Load Bearing Frames
2.4 - Hydraulic Jack
2.5 - Loading Power Supply
2.2 Construcon
The outline drawing in Figure 4 illustrates the overall construcon of the calibrang machine. Dimensions are
indicated for the various standard capacity machines in Tables 1 and 2. The machine is built to be plumb, level,
square, rigid, and have low torsion.
2. Descripon
