Morehouse UCM - Overview

Universal Calibrang Machine
(UCM) Manual
(PM-5201)
Morehouse Instrument Company, Inc.
1742 Sixth Ave., York, PA 17403-2675 USA
Phone: (717) 843-0081
www.mhforce.com
Page 6
Rev. 3/2024
Figure 3: Morehouse Universal Calibrating Machine 100,000 lbf (500 kN) Capacity
(with motorized adjustable yoke platen)
1.5 Overview
This manual contains instrucons for the installaon, operaon, service, and roune maintenance of all More-
house Universal Calibrang Machines, regardless of capacity. If there are any quesons about the use or main-
tenance of the calibrang machine, please contact us at info@mhforce.com.
Hand Pump Assembly
Stationary Frame Assembly
Adjustable Foot
Hydraulic Jack Assembly
Motorized Positioning Mechanism
Moveable Yoke Assembly
Lower Yoke Platen
Upper Yoke Platen
Drive Mechanism Housing
Tension Tie Bar
Tie Bar Locking Collar
Upper Machine Platen
Reference Standard Load Cell
Set Screw
Lower Machine Platen
Momentary Positioning Switch
Hydraulic Screw Pump
Unit Under Test in Tension
