Morgan Schaffer Calisto - Operation and Construction Specifications

72
Power interruption protection
250 ms advanced power loss system
Expected Operating Life (EOL)
> 15 years
Operating temperature range (standard)
-40 to 55°C (-40 to 131°F)
Storage temperature range
-30 to 75°C (-22 to 167°F)
Operating oil temperature range
-40 to 120°C (-40 to 248°F)
Operating oil pressure range
Full vacuum to 2.7 bar (40 psi)
Operating humidity range
0 – 100% RH
Storage humidity range
5 – 95% RH, non-condensing
Altitude range
Up to 4,000 m (13,000 ft)
Width × Height × Depth
381 × 483 × 325 mm (15 × 19 × 12.8 in)
Weight
22.7 kg (50 lbs)
Enclosure
SS 304 gauge 16, lockable
Oil circulation
Anti-cavitation reciprocating pump,
10 - 60 ml/min.
Oil flow monitoring
Proprietary Morgan Schaffer system
Oil lines (standard)
3/8" O.D. copper with brass compression
fittings
Enclosure temperature conditioning
Thermoelectric feedback
Oil temperature conditioning
Passive heat exchanger
Thermoelectric feedback
Cooling
Forced air convection
Safety protection
Thermal cut-off fuse, rated at 77°C (171°F)
Over current protection fuse
Oil sampling
External quick-connect port with sampling
accessories
