Morgan Schaffer Calisto - Installation and Connectivity Specs

73
Calibration
No calibration required
Maintenance
Annual visual inspection
Electrical entry holes (standard)
4 × 22.2 mm (0.875 in) diameter
Commissioning time
2 hrs
Mounting
Vibration mounts. Morgan Schaffer Calisto
Mounting Stand recommended
Power requirements
100 – 240 VAC, 50 – 60 Hz, 320 W, 1 Ø
Power conductor size
Max. 2.5 mm
2
(AWG 12)
Oil supply line length
1.5 – 10.5 m (5 – 35 ft)
Oil return line length
1.5 – 10.5 m (5 – 35 ft)
Display
114×16-pixel vacuum fluorescent, day/night
Local
USB 2.0 type B port (cable provided)
Permanent connection
RS-485 port (1,500 V isolation)
RS-232 port (1,500 V isolation)
Ethernet port (1,500 V isolation)
Independent H
2
, CO and H
2
O analog outputs,
4 – 20 mA (1500 V isolation)
Oil temperature analog input, 4– 20 mA (1500
V isolation)
Communication protocols
MSSP (Morgan Schaffer Systems Protocol)
Modbus, DNP3 Level1
Optional IEC 61850 kit
Measurement Alarms
Programmable dual-level and trend alarms for
H
2
, CO (Calisto 2 only) and H
2
O
Alarm Relays
5 NO/NC contacts, configurable for setup,
self-test and measurement alarm conditions
(5A, 240V)
Data update
8 readings/day, validated H
2
8 readings/day, validated CO (Calisto 2 only)
1 reading/5 sec., continuous H
2
and H
2
O
Data storage
3000 (1 year)
Calisto Access interface software
Win 98 / 2000 / NT / XP / Vista / 7
