13. Temple stabilizers and chinrest
Turn the temple stabilizer knob to make sure the stabilizers open and close properly. Make sure the
chinrest and lip-nose rest are secure in both their upper and lower positions.
14. Lift Mechanism
Press the up and down keys.
Make sure the lift moves smoothly and stops properly. Repeat this 3 times.
15. Wire Cables
Check the wire cables for broken strands. Make sure the ends are properly secured. Grease the cables with
the grease provided by the manufacturer.
16. Operation panel and display
Press all the keys on the operation panel and display and make sure they work.
Press all the keys on the patient frame and make sure they work.
Make sure the LED on the control box lights up when the Ready key is pressed.
17. X-ray Emission and Display
Make sure the Emission LED (yellow) on the control box lights up during X-ray emission and that the
audible signal sounds.
18. Digital Cassette
Press the lock button and make sure the lock pin moves smoothly.
Repeat 3 times.
19. Digital Cassette
Visually inspect connector. Make sure it is not cracked and that the pins are not bent.
20. Oil Leak
Check for the oil leak, if the insulation oil filled in the tube head assembly in X-ray Head from the outside
of the enclosure. *Oil leak check from the tube head assembly inside the enclosure may only be done by
the accredited service personnel.
Panorama Exposures
1. X-ray emission and image read-in
Make an X-ray exposure of a test piece and check the resulting image in the computer monitor.
2. Arm Rotation
Hold down the emission button to rotate the arm.
Make sure it does not make an abnormal noise or slip and that it stops at the specified point.
3. Arm Emergency Stop
Make sure the arms stops when the emission button is released and when the emergency stop switch is
pressed.
4. DDAE Verification
To Next Page
