SECTION 6
50
Summary of Configuration Menus (Continued)
Parameter Options
Use A4 paper YES/NO
Caps lock YES/NO
Rhythm Format 3, 6, or 12 channel
3 Rhythm Lead 1
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
3 Rhythm Lead 2
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
3 Rhythm Lead 3
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
6 Rhythm Lead 1
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
6 Rhythm Lead 2
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
6 Rhythm Lead 3
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
6 Rhythm Lead 4
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
6 Rhythm Lead 5
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
6 Rhythm Lead 6
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
History Lead
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
ECG Mode
12 lead, 15 lead (V3R, V4R, V7), 15 lead (V7, V8, V9)
15 lead (E1, E2, E3)
Plot Format 3+1, 6, 3+3, 12, 6+6, and Cabrera
3+1 Rhythm lead
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
3+3 Rhythm lead 1
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
3+3 Rhythm lead 2
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
3+3 Rhythm lead 3
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
optional V3R, V4R, V7 or V7, V8, V9 or E1, E2, E3
XMT (Sync) Media RS-232, Modem, LAN, WLAN-Veyron
DHCP (active for LAN or WLAN) YES/NO
IP Address (active for LAN or WLAN) XXX.XXX.XXX.XXX
Def. Gateway (active for LAN or WLAN) XXX.XXX.XXX.XXX
Sub Net Mask (active for LAN or WLAN) XXX.XXX.XXX.XXX
Host IP (active for LAN or WLAN) XXX.XXX.XXX.XXX
Port Number (active for LAN or WLAN) XXXX
WLAN Connect Standard or Fast
SSID (present for WLAN) No SSID or SSID
Comm. Protocol UNIPRO, UNIPRO 32, DICOM, or DICOM 32
WLAN Security
None, WEP128, WEP64, WPA-PSK, WPA-LEAP, WPA-PSK64,
WPA-PSK128, WPA-LEAP64, WPA-LEAP128, WPA2-PSK, or
WPA2-PEAP
To Next Page
