What does 'Unknown Device' mean on Mortara Medical Equipment?
If the system displays “Unknown Device” or “Unknown Manufacturer”, the TRPC or EPC is not recognized due to an incorrect installation or lack of installation of the device driver. Note that TRPC or EPC is not compatible with X-Scribe V3.10. You will need an MMM device and drivers.
What to do if squared lines appear on Mortara X-Scribe display?
If you see squared lines on the multi-lead rhythm display or during an exercise test, it may be due to a lead fail from poor skin-to-electrode contact, a broken lead wire/cable, or a channel mismatch between the transmitter and X-Scribe. Correct the faulty lead(s) identified in the upper right corner of the screen. If needed, replace the patient cable or match the channel of the transmitter to the channel on X-Scribe.
Why won't my Mortara X-Scribe Medical Equipment treadmill turn on?
If the treadmill does not respond to the ON command from X-Scribe, it might be due to incorrect power-up sequence, the treadmill power switch being off, an improperly attached treadmill cable, an engaged emergency stop switch, or incorrect treadmill settings. Turn the treadmill OFF using the Softkey menu, then turn the power to the treadmill OFF. Wait one minute, then turn the power back ON and proceed with the test. Ensure the treadmill to X-Scribe cable connections are secure and the treadmill main power switch is ON (located at the base of the treadmill hood, left side). Reset the emergency stop switch by turning it clockwise one-quarter turn. Reset X-Scribe. Set the treadmill to the proper setting for the corresponding treadmill.
How to reduce muscle noise in Mortara Medical Equipment readings?
Muscle noise can occur if the electrode is placed over muscle or fatty tissue. To fix this, find a stable electrode site, re-prep the skin, and apply a new electrode.
How to correct baseline drift on Mortara Medical Equipment?
Baseline drift can be caused by poor skin-to-electrode contact. Re-prep the skin and replace the faulty electrode to resolve this issue.
What to do for ECG Front-End Error on Mortara X-Scribe?
If the ECG Front-End Error occurs, and you can’t proceed, it could be that the MMM device is not correctly connected or that there are incorrect Power Savings settings. Try disconnecting the USB cable from the PC and then reconnecting it. The system should emit a confirmation beep. If rebooting fixes the problem, the system likely has incorrect Power Saving settings. To correct this: 1. Close the X-Scribe application. 2. Select “Start”, “Settings”, then “Control Panel”. 3. Double click on “Power Management” icon. 4. If displayed, set “Stand-by” setting to “Never”. 5. Click OK and close all open Windows. 6. Reboot system.
How to select a stage on Mortara X-Scribe?
If you try to edit a stage in the edit/create protocol function but no stage is selected, double click on the stage to edit. This will open the edit window and give access to all stage parameters.
What does 'No Exams are Currently Selected' mean on Mortara Medical Equipment?
If you see 'No Exams are Currently Selected', it may be due to an attempt to access a final report without selecting a patient from the list. Click on the patient name to select and access the file.
Why is there a BP printout discrepancy on my Mortara X-Scribe?
A discrepancy between the BP printout and report can occur if the BP field is used to enter new blood pressure values. The BP value MUST BE entered through the F3 key. Editing of BP is completed through the selection of the BP value on the right side of the display. The edited value will erase the previously entered value from the summary report.
How to troubleshoot packet errors on Mortara Medical Equipment?
If you are experiencing packet errors or signal drop (wireless option), and the signal onscreen shows artifact even when tested with a simulator, check that no medical equipment is operating at the same frequency in proximity to the system. Run the built-in spectrum analyzer to locate the source of the interference and to set the proper channel on the digital transmitter.
General| Brand | Mortara |
|---|---|
| Model | X-Scribe |
| Category | Medical Equipment |
| Language | English |
Defines symbols for warnings, cautions, and notes to ensure safe operation.
Provides essential safety guidelines for operating the device.
Ensures electrical safety and patient protection during use.
Highlights hazards like defibrillation, flammable anesthetics, and improper use.
Outlines the manual's scope and intended reader.
Defines the device's purpose and when it should be used.
Details the X-Scribe system, its features, and included parts.
Lists the technical specifications of the X-Scribe system.
Step-by-step guide for assembling and installing the X-Scribe system.
Visual guide to system connections and details on the isolation transformer.
Instructions for powering on and launching the X-Scribe software.
Overview of the X-Scribe's functions and features.
Explanation of the graphical user interface and on-screen data.
Details the use of function keys for system control.
Steps for preparing the patient and attaching electrodes.
Guides on applying filters like SCF, AC, and 40 Hz.
Details on test phases: Pre-Exercise, Exercise, Recovery, and Final Report.
Procedures for managing, printing, and archiving test reports.
Configuring AC frequency, RF channels, and performing RF scans.
Creating, modifying, and selecting user profiles and exercise protocols.
Setting up network data export/import and standard user configurations.
Guidelines for regular equipment cleaning and upkeep.
Diagnosing issues and recording system details for service.
