Mortara ELI 350 - Summary of Configuration Options

SECTION 6
49
Summary of Configuration Menus
Parameter Options
Software version Displays software version on printout and display
Cart Number Numeric field 0 to 65535
Site Number Numeric field 0 to 4095
Site Name Alphanumerical field (30 digits)
Telephone number Alphanumerical field (45 digits)
Language Available software languages
Volume Numerical field 0 to 8
Battery Time Out 1 min, 5 min, 10 min, 20 min
Brightness AC Auto, Low, Middle, or High
Brightness Battery Auto, Low, Middle, or High
ID Format Short, Standard, Long, or Custom
AC Filter 50 Hz, 60 Hz, or None
ECG Display Speed 25 or 50 mm/sec
ECG Print Speed 25 or 50 mm/sec
Rhythm Print Speed 5, 10, 25, or 50 mm/sec
Filter Frequency response for printouts: 40 Hz,150 Hz, or 300 Hz
Ht/Wt Units Lb/in or Kg/cm
Interp YES/NO
Avg RR YES/NO
QTcB YES/NO
QTcF YES/NO
Worklist Management Standard or Refresh
SYNC Button
Transmit the ECG or transmit the ECG and request an automatic
download of orders, Time Sync and transmit ECG, or Time Sync,
Transmit ECG, and Download orders..
Mandatory Demographic None, Last Name, Patient ID, or Last Name and Patient ID
Serial Comp. Active No/Text/Text + Waveforms
# ECG Comp. 1, 2, 3, 4
Append UNCONFIRMED REPORT, Reviewed by
Reasons YES/NO
# Copies 0 to 9
Copies with Interp YES/NO
# ECGs Retrieved 0 to 7
Delete Rule Post Plot, Post Transmit, Post Plot/Xmt
Storage Sensitivity NORMAL or HIGH
Auto-save ECG YES/NO
Auto-print ECG YES/NO
ECG Capture Best 10 or Last 10
Baud rate 9600, 19200, 38400, 57600, 115200
