Motic BA210 - Nomenclature

6
1. Nomenclature
Eyepiece
Diopter adjustment ring
Eyepiece lock screw
Specimen holder
Condenser focus knob
Coarse focus torque
adjustment ring
Fine focus knob
Coarse focus knob
Interpupillary distance scale
Field lens
Stage X-Axis travel knob
Stage Y-Axis travel knob
Stage
Objective
Binocular eyepiece tube
Revolving nosepiece
Condenser
aperture scale
Condenser
position lock
Condenser
aperture lever
Condenser
clamp screw
