EN
29
The CE24BNC control unit is the most modern, ecient system for
the control of Motorisation Plus motors for the electric opening and
closure of swing gates.
All other, improper, use of the control unit is forbidden. The
CE24BNC has a display allowing easy programming and constant
monitoring of the input status; the menu structure also allows easy
setting of working times and operating modes.
2.3 - Description of the control unit
2.4 - Description of the connections
1. Motor power supply connections
2. Transformer power supply connections
3. 24Vdc and 24Vac output connections to controls and safety
devices
4. Connector for battery charger BAT371
5. Connection of ashing light, courtesy light, gate open
indicator light/electric lock
6. Functions display
7. Safety device dip switch
8. Fuse 2AT slow-acting
9. STOP-PH2-PH1-OPEN-CLOSE-PAR-SBS safety led and
input led
10. STEPPING SBS button
11. UP + button up
12. MENU button menu
13. DOWN - (DOWN) button down and radio menu
14. Antenna
15. led
Code Description
RUN24 Gear motor for hinged doors with max length 2,3 m and weight 250 Kg, 24 Vdc
2 - INTRODUCING THE PRODUCT
TECHNICAL DATA
MODELS RUN24
Torque Nm 120
Working cycle Cycles/Hour 60
Opening time at 90° sec 14-20
Control board CE24BNC
Power supply Vac 230
Power supply Vdc 24
Absorption A 0,6
Engine power W 115
Integrated lights no
Degree of protection IP 44
Dimensions (L - P - H) mm 125 - 260 - 310
Weight Kg 10,5
Operating temperature °C -20°+55°
Leaves maximum weight Kg 250
The RUN24 gear motors are destined to be installed in systems for
the automation of gates with hinged doors.
The RUN24 gear motors have been designed and constructed
to be tted onto hinged doors within the weight limits indicated
in the technical specications table. The use of gear motors for
applications which dier from those indicated above is prohibited.
2.1 - Description of the product
2.2 - Model and technical characteristics
