Motorola 6864115B62-C

1-2 MODEL CHART AND TECHNICAL SPECIFICATIONS
2.0 GM340/GM360/GM380 Model Chart
GM Series VHF 136-174 MHz
Model Description
MDM25KHC9AN1_E GM340, 136-174 MHz, 1-25W, 6 Ch
MDM25KHF9AN5_E GM360, 136-174 MHz, 1-25W, 255 Ch
MDM25KHC9AN8_E GM380, 136-174 MHz, 1-25W, 255 Ch
MDM25KHA9AN0_E Databox, 136-174 MHz, 1-25W, 16 Ch
Item Description
X GCN6112_ Control Head GM340
X GCN6120_ Control Head GM360
X GCN6121_ Control Head GM380
X GCN6116_ Databox Radio Blank Head
X IMUD6013_S Field Replaceable Unit (Main Board) GM340
X IMUD6013_S Field Replaceable Unit (Main Board) GM360
X IMUD6024_S Field Replaceable Unit (Main Board) GM380
X IMUD6015_A S/T 136-174MHz 1-25 SEL5
X X X X ENBN4056_ Packaging, Waris Mobile
X X X X GLN7324_ Low Profile Mounting Trunnion
X X X X HKN4137_ 12V Power Cable 1-25W
X X X MDRMN4025_ Enhanced Compact Microphone
X 6864110B80 User Guide GM340
X 6864110B81 User Guide, GM360
X 6864110B82 User Guide, GM380
X = Indicates one of each is required
