UHF 1-25W PCB 8471224L01 / Schematics 4-46
C4453 2113944C45 CAP 100 PF
C4455 2111078B12 CAP 9.1 PF
C4457 2111078B27 CAP 30 PF
C4458 2111078B32 CAP 39 PF
C4459 2113944C45 CAP 100 PF
C4471 2113944C45 CAP 100 PF
C4472 2111078B31 CAP 36 PF
C4473 2111078B31 CAP 36 PF
C4474 2113944C45 CAP 100 PF
C4475 2113944C71 CAP 5.6 PF
C4491 2111078B12 CAP 9.1 PF
C4492 2111078B32 CAP 39 PF
C4496 2111078B09 CAP 6.8 PF
C4497 2111078B07 CAP 5.6 PF
C4501 2113945L33 CAP 2200 PF
C4502 2113945C04 CAP 0.022 UF
C4503 2113945C31 CAP 0.1 UF
C4504 2113945C18 CAP 0.012 UF
C4505 2313960B01 CAP 1 UF
C4506 2113945L33 CAP 2200 PF
C4507 2113944C45 CAP 100 PF
C4508 2113944C45 CAP 100 PF
C4510 2113944C45 CAP 100 PF
CR4301 4885094Y01 DIODE VCTR ISV 228
CR4302 4885055Y01 DIODE VARACTOR
CR4303 4885055Y01 DIODE VARACTOR
CR4311 4815322H01
DIODE VARIABLE
CAPACITANCE
CR4321 4885055Y01 DIODE VARACTOR
D3101 4815048H01 DIODE SCHOTTKY MIXER
D4001 4885055Y01 DIODE VARACTOR
D4002 4885055Y01 DIODE VARACTOR
D4003 4815048H01 DIODE SCHOTTKY MIXER
D4004 4885055Y01 DIODE VARACTOR
D4005 4885055Y01 DIODE VARACTOR
D4006 4813974A06 DIODE MMBV109
D4007 4813978C02 DIODE DUAL 70V
D4051 4886143B01 MIXER QUAD RING DIODE
D4201 4815011H01 DIODE TRIPLE SOT25-RH
D4221 4813974A05 DIODE MMBD301L
D4401 4813978C02 DIODE DUAL 70V
D4451 4813974A05 DIODE MMBD301L
D4471 4802482J02 PIN DIODE
D4472 4802482J02 PIN DIODE
FL3101 9180112R16 CRYSTAL FILTER 44.85MHz
FL3102 9180112R16 CRYSTAL FILTER 44.85MHz
Circuit
Ref
Motorola
Part No.
Description
FL3111 9115811H01
6 ELEMENT CER FLTR
455KHz
FL3112 9115811H04
6 ELEMENT CER FLTR
455KHz
FL3114 9180468V06
4 ELEMENT CER FLTR
455KHz
FL3115 9115811H02
6 ELEMENT CER FLTR
455KHz
J4401 0986166B01 RF CONNECTOR (BNC)
L3101 2414032D25 IND 620 NH
L3111 2414032D25 IND 620 NH
L3112 2414032D25 IND 620 NH
L3124 2414032B68 IND 1000 NH
L4003 2414032D23 IND 470 NH
L4006 2414032F24 IND 15 NH
L4008 2414032D23 IND 470 NH
L4051 2414032D17 IND 150 NH
L4053 2414032B46 IND 27 NH
L4054 2414032B43 IND 15 NH
L4201 2414017Q42 IND 390 NH
L4221 2414032L25 IND 1200 NH
L4231 2414017Q20 IND 2200 NH
L4301 2414032D22 IND 390 NH
L4302 2414032D22 IND 390 NH
L4303 2460593C01 RESONATOR
L4304 2414032D22 IND 390 NH
L4305 2414032D22 IND 390 NH
L4311 2414032D22 IND 390 NH
L4312 2460593C01 RESONATOR
L4313 2414032D22 IND 390 NH
L4331 2414032D09 IND 33 NH
L4333 2414032D22 IND 390 NH
L4361 2414032D09 IND 33 NH
L4362 2414032D09 IND 33 NH
L4371 2414032D13 IND 68 NH
L4401 2460591B04 IND 11.03 NH
L4402 2415954H02 INDUCTOR BEAD
L4403 2414032B50 IND 56 NH
L4411 2414032B44 IND 18 NH
L4421 2415954H02 INDUCTOR BEAD
L4422 2460591A01 IND 4.22 NH
L4436 2415954H02 INDUCTOR BEAD
L4437 2460592A01 IND 17 NH
L4471 2414032D22 IND 390 NH
L4472 2460592A01 IND 17 NH
L4491 2460592A01 IND 17 NH
Circuit
Ref
Motorola
Part No.
Description
L4493 2460592A01 IND 17 NH
M3421 2686201B02 HEAT SPREADER
Q3101 4802197J95 TRANSISTOR PBR941
Q3102 4802197J95 TRANSISTOR PBR941
Q3141 4813973M07 TRANSISTOR MMBT3904
Q3151 4813973A42 TRANSISTOR NPN DIGITAL
Q3152 4813973A42 TRANSISTOR NPN DIGITAL
Q4002 4813973A13 TRANSISTOR PNP40V
Q4003 4802197J95 TRANSISTOR PBR941
Q4004 4816097H01 TRANSISTOR FMC2
Q4221 4813973A42 TRANSISTOR NPN DIGITAL
Q4301 4805218N63 TRANSISTOR BFQ67W
Q4332 4802197J95 TRANSISTOR PBR941
Q4333 4815055H01 TRANSISTOR DUAL UMH 5
Q4411 4816097H01 TRANSISTOR FMC2
Q4421 4813976A04 TRANSISTOR MRF1518
Q4422 4813973A42 TRANSISTOR NPN DIGITAL
Q4441 4813976A13 TRANSISTOR LDMOS
Q4442 4813973A42 TRANSISTOR NPN DIGITAL
Q4471 4813973A42 TRANSISTOR NPN DIGITAL
Q4472 4805128M27 TRANSISTOR SOT
R3101 0613952J03 RES 12K Ohm
R3102 0613952H25 RES 10 Ohm
R3105 0613952H49 RES 100 Ohm
R3106 0613952J11 RES 27K Ohm
R3107 0613952H82 RES 2400 Ohm
R3108 0613952H75 RES 1200 Ohm
R3111 0613952J03 RES 12K Ohm
R3112 0613952H25 RES 10 Ohm
R3113 0613952H61 RES 330 Ohm
R3115 0613952H63 RES 390 Ohm
R3116 0613952H81 RES 2200 Ohm
R3117 0613952J11 RES 27K Ohm
R3118 0613952H82 RES 2400 Ohm
R3124 0613952H73 RES 1000 Ohm
R3130 0613952H42 RES 51 Ohm
R3132 0613952J05 RES 15K Ohm
R3133 0613952H89 RES 4700 Ohm
R3134 0613952H95 RES 8200 Ohm
R3135 0613952H75 RES 1200 Ohm
R3141 0613952H63 RES 390 Ohm
R3142 0613952H79 RES 1800 Ohm
R3144 0613952H82 RES 2400 Ohm
R3145 0613952H85 RES 3300 Ohm
R3146 0613952H69 RES 680 Ohm
R3147 0613952J03 RES 12K Ohm
Circuit
Ref
Motorola
Part No.
Description
R3148 2113944C45 CAP 100 PF
R3151 0613952J01 RES 10K Ohm
R3152 0613952J01 RES 10K Ohm
R3153 0613952J01 RES 10K Ohm
R3154 0613952J01 RES 10K Ohm
R4001 0613952J25 RES 100K Ohm
R4002 0613952H61 RES 330 Ohm
R4003 0613952H87 RES 3900 Ohm
R4004 0613952H83 RES 2700 Ohm
R4005 0613952J01 RES 10K Ohm
R4007 0613952H49 RES 100 Ohm
R4012 0613952J25 RES 100K Ohm
R4013 0613952H59 RES 270 Ohm
R4014 0613952H25 RES 10 Ohm
R4016 0613952H85 RES 3300 Ohm
R4018 0613952H85 RES 3300 Ohm
R4022 0613952G67 RES 0 Ohm
R4051 0613952H42 RES 51 Ohm
R4052 0613952G67 RES 0 Ohm
R4060 0613952J37 RES 330K Ohm
R4061 0613952J01 RES 10K Ohm
R4062 0613952H77 RES 1500 Ohm
R4063 0613952H63 RES 390 Ohm
R4064 0613952G67 RES 0 Ohm
R4068 0613952H77 RES 1500 Ohm
R4069 0613952H73 RES 1000 Ohm
R4070 0613952H63 RES 390 Ohm
R4071 0613952J01 RES 10K Ohm
R4072 0613952J01 RES 10K Ohm
R4201 0613952H53 RES 150 Ohm
R4203 0613952H41 RES 47 Ohm
R4204 0613952H41 RES 47 Ohm
R4211 0613952G67 RES 0 Ohm
R4221 0613952H53 RES 150 Ohm
R4222 0613952H66 RES 510 Ohm
R4223 0613952H45 RES 68 Ohm
R4224 0613952J17 RES 47K Ohm
R4225 0613952J17 RES 47K Ohm
R4228 0613952J01 RES 10K Ohm
R4241 0613952H57 RES 220 Ohm
R4251 0613952J15 RES 39K Ohm
R4252 0613952J12 RES 30K Ohm
R4261 0613952J17 RES 47K Ohm
R4263 0613952H49 RES 100 Ohm
R4301 0613952H91 RES 5600 Ohm
R4302 0613952J01 RES 10K Ohm
Circuit
Ref
Motorola
Part No.
Description
