Installation Guide 5
1 Introduction
The AP6532 Access Point, a component of the Motorola Solutions Wireless Controller System, links wireless
802.11a/b/g/n devices to the controller, enabling growth of your wireless network with a cost effective alternative
to standard Access Points. The AP6532 Access Point provides two placement options: wall and ceiling. Wall mount
slots fit onto two provided screws. Arrows on the case guide the placement of the screws. For placement above a
suspended ceiling, a safety wire tie point on the case provides for a safety wire loop. The light pipe fits through a
hole in the ceiling tile to provide a view of the unit’s status lights.
The AP6532 Access Point receives all power and transfers data through the same CAT-5 or better Ethernet cable.
There is no additional power supply required. An 802.3af Ethernet switch or power injector is required.
1.1 Document Conventions
The following graphical alerts are used in this document to indicate notable situations:
1.2 Warnings
• Read all installation instructions and site survey reports, and verify correct equipment installation before
connecting the AP6532 Access Point.
• Remove jewelry and watches before installing this equipment.
• Verify that the unit is grounded before connecting it to the power source.
• Verify that any device connected to this unit is properly wired and grounded.
• Verify there is adequate ventilation around the device, and that ambient temperatures meet equipment
operation specifications.
NOTE Tips, hints, or special requirements that you should take note of.
CAUTION Care is required. Disregarding a caution can result in data loss or
equipment malfunction.
WARNING! Indicates a condition or procedure that could result in personal injury or
equipment damage.
