Installation Guide 7
1.5 Features
• One RJ-45 connector
• LED indicators
• Safety wire tie point
• Slots for wall mounting
• Clips for mounting on a suspended ceiling T-bar
• Lock port for Kensington® style Security Lock
The AP6532 Access Point has one RJ-45 connector supporting an 10/100/1000 Ethernet port and requires
802.3af-compliant power from an external source.
The AP6532 Access Point comes with dual radios both supporting 802.11a/b/g/n.
The Access Point contains runtime firmware which enables the unit to boot after a power up or watchdog reset.
The runtime firmware on the Access Point and the firmware downloaded from the controller can be updated via the
Ethernet interface from the Wireless Controller.
NOTE When operating in a Gigabit Ethernet environment, CAT-5e or CAT-6 cable
is recommended for Gigabit operation.
