Motorola APX 3000 Basic Service Manual

Exploded Views and Parts Lists: APX 3000 Back Kit Exploded View Parts List 10-5
10.4 APX 3000 Back Kit Exploded View Parts List
NOTE:
†
. Items cannot be ordered individually.
††
. RF Board Kit for different bandsplit.
†††
. Items can be ordered individually but they are included in the chassis back kit.
†††*
Items are not in chassis back kit, but can be ordered individually.
**Items orderable for depot and FM qualified customers/dealers only.
Item
No.
Motorola Part
Number
Description
25
†††*
0386104Z04 Screw, Chassis
26
†††*
26012242001 Shield, Secondary
27
†††*
43012045001 Collar, Plastic
28
†††*
32012212001 Main, Seal
29
††
MLF4094AZ
MLE4858AZ
MLE4912
MLD4565
RF Board Kit, 700/800 MHz
RF Board Kit, UHF1
RF Board Kit, UHF2
RF Board Kit, VHF
30
†††
75012184001 Pad, Poron, BTB, 12pin, Plug, NFC
31
†††*
75012182001 Pad, Thermal & Conductive
32
†††
0104052J74 Assy, Flex, NFC
33
†††
27012023001 Chassis
34
†††
54012285001 Label, Chassis Left
35
†††
54012285002 Label, Chassis Right
36
†††
61012070001 Lightpipe, LEDs
37
†††
15012209001 Shroud
38
†††
54012276001 Label, Shroud
39
†††
54012253001 Bluetooth Pairing Indication Label
40
†††*
32012150001 Seal, Battery Contact
41
†††
54012279001 Label, FM**
42
†
54012242001 Label, FCC
43
†††
54012298001 Label, Gore Port
44
†
33012034001 Label, ITID
45
†††*
3286058L01 Seal, Vacuum Port
46
†††
54012283001
54012283002
Label, Bottom Blank
Label, FM Approved Logo (Bottom)**
47
†††*
6071520M01 Batt Coin 3V Li Rechargeable
