Disassembly/Reassembly Procedures: Required Tools and Supplies 8-3
8.2 Required Tools and Supplies
8.3 Fastener Torque Chart
Table 8-3 lists the various fasteners by part number and description, followed by the torque values
and the location where used. Torque all fasteners to the recommended value when assembling the
radio.
Table 8-2. Required Tools and Supplies
Tools
Motorola
Part Number
Supplier
Supplier Part
Number
Remarks
Chassis Opener PMLN6208_ Horizon
Land
– To remove chassis from housing.
Bit, Torx T6 – – – For 2nd Shield & Main PCB & Shroud.
Black Stick – Hexacon
Electric Co.
MA-800G For removing the shroud from chassis.
Driver, Torque – – – –
Allen wrench – – – To loosen accessory-connector cover thumb
screw (if thumb screw is too tight).
Anti-static ground
kit
0180386A82 – – To place radio and components during
disassembly and reassembly.
Vacuum Pump kit NLN9839_ Motorola – For vacuum test. Requires 66012075001
Vacuum Test Fixture.
Vacuum Test
Fixture
66012075001 Brusia BE-MO-121242 To connect the vacuum/pressure hose of the
Vacuum Pump Kit to the radio.
Table 8-3. Required Tools and Supplies
Motorola
Part Number
Description Repair Torque (in-lbs)
0386104Z04 Screw, 2nd Shield & Main PCB &
Shroud.
3.0
