Motorola APX 3000 Basic Service Manual

xxii ASTRO APX 3000 UHF2 Model Chart
ASTRO APX 3000 UHF2 Model Chart
Model Number:
BT Models FCC ID:
MODEL DESCRIPTION:
H59SDD9PW4AN
AZ489FT4912
APX COVERT UHF2 MODEL 1 PORTABLE
ITEM NUMBER DESCRIPTION
X 0104052J79 Front Housing Kit (APX 3000)
X 0104052J59 Assy, Flex, Top Control
X 41012013001 Spring, Switch, Rotary
X 07012048001 Bracket, Top Control
X 0104052J80 Back Housing Kit (APX 3000)
X 0104052J74 Assy, Flex, NFC
X 75012184001 Pad, Poron, BTB, 12pin, Plug, NFC
X 27012023001 Chassis
X 54012285001 Label, Chassis Left
X 54012285002 Label, Chassis Right
X 61012070001 Lightpipe, LEDs
X 15012209001 Shroud
X 54012276001 Label, Shroud
X 54012253001 Bluetooth Pairing Indication Label
X 32012212001 Main Seal
X 32012150001 Seal, Battery Contact
X 6071520M01 Batt Coin 3V LI Rechargeable
X 26012242001 Shield, Secondary
X 0386104Z04 Screw Chassis
X 3286058L01 Seal, Vacuum Port
X 43012045001 Collar, Plastic
X 75012182001 Pad, Thermal & Conductive
X 54012298001 Label, Gore Port
X
MLE4912_
RF Board Kit UHF2
● 54012279001 Label, FM
● 54012283002 Label, FM Approved Logo (Bottom)
● 54012283001 Label, Bottom Blank
● 15012210001 GCAI, Dust Cover
X PMLN6408_ User Guide CD, APX 3000
Note:
X = Item Included.
O = Option available.
● = Option available.Can be serviced in depot and orderable by FM qualified customers/dealers only.
= For APAC - Only FM label can be replace and purchased by Motorola.
• Refer
Appendix A for antennas, batteries and other applicable accessories.
