Specifications for APX 3000 700-800 MHz Radios
All specifications are per Telecommunications Industries Association TIA-603 unless otherwise
noted.
GENERAL RECEIVER TRANSMITTER
Temperature Range:
Operating: -30°C to +60°C
Storage: -40°C to +85°C
Power Supply:
Lithium-Ion Battery (Li-Ion)
Battery Voltage:
Nominal: 7.5 Vdc
Range: 6 to 9 Vdc
Transmit Current Drain (Typical): 1670 mA
Receive Current Drain (Rated Audio): 319 mA
Standby Current Drain: 138 mA
Recommended Battery:
Li-Ion (Ultra Slim): NNTN8305_
or Li-Ion (Slim): NNTN8128_
or Li-Ion High Cap: NNTN8129_*
or Li-Ion High Cap: PMNN4424_
* FM Intrinsically Safe.
Dimensions (H x W x D):
Without Battery (Radio Only):
H = 5.57" (141.5mm)
W1 = 2.37" (60.1mm) / 2.35" (59.8mm)
D2 = 1.07"(27.03mm) / 1.06"(27.03mm)
With Ultra-Slim Battery:
H = 5.57" (141.5mm)
W1 = 2.37" (60.1mm) / 2.35" (59.8mm)
D2 = 1.47"(37.4mm) / 1.72"(43.6mm)
With Slim Battery:
H = 5.57" (141.5 mm)
W1 = 2.37" (60.1 mm) / 2.35" (59.8mm)
D2 = 1.47"(37.4mm) / 1.72"(43.6mm)
With High Cap Battery:
H = 5.57" (141.5mm)
W1 = 2.37" (60.1mm) / 2.35" (59.8mm)
D2 = 1.69"(42.9mm) / 1.93"(48.9mm)
Note:
H = Height; W = Width; D = Depth
1 = (Width @ Top)
2 = (Depth @ Bottom)
Weight: (w/o Antenna):
Less Battery: 6.84 oz (260g)
With Li-Ion Standard: 14.47 oz (410g)
With Li-Ion High Cap: 14.81 oz (420g)
FCC ID:
AZ489FT5860
Frequency Range:
700 MHz: 764–776 MHz
800 MHz: 851–870 MHz
Bandwidth:
700 MHz: 12 MHz
800 MHz: 19 MHz
Analog Sensitivity (typical)
(12 dB SINAD): 0.266 µV
Digital Sensitivity (typical)
(1% BER): 0.400 µV
(5% BER): 0.266 µV
Intermodulation (typical): -75 dB
Selectivity
(typical):
(25 kHz Channel): -76 dB
(12.5 kHz Channel): -67 dB
Spurious Rejection (typical): -76.6 dB
Frequency Stability
(-30+60°C; 25°C reference): ±0.0001%
Rated Audio:
External Speaker: 500 mW
FM Hum and Noise (typical):
25 kHz -53 dB
12.5 kHz -47 dB
Distortion (typical): 1 %
Channel Spacing: 12.5/25 kHz
Frequency Range:
700 MHz: 764–775; 793–805 MHz
800 MHz: 806–824; 851–869 MHz
RF Power:
700 MHz: 1–2.5 Watts
800 MHz: 1–3.0 Watts
Frequency Stability (typical)
(-30 to +60°C; 25°C ref.):
700 MHz: ±0.0001%
800 MHz: ±0.0001%
Emission (typical conducted): -75 dBc
FM Hum and Noise (typical)
(Companion Receiver): 25 kHz -50 dB
12.5 kHz -45 dB
Distortion (typical): 1%
Modulation Limiting: 25 kHz chnls ±5 kHz
20 kHz chnls ±4 kHz
12.5 kHz chnls ±2.5 kHz
ACPR (typical): 25 kHz -72 dBc
12.5 kHz -66 dBc
Emissions Designators:
11K0F3E, 16K0F3E, 8K10F1D, 8K10F1E,
8K10F1W, 20K0F1E
Specifications subject to change without notice.
