4-2 Recommended Test Equipment and Service Aids: Service Aids
4.2 Service Aids
Refer to Table 4-2 for a listing and description of the service aids designed specifically for servicing
this family of radios. These kits and/or parts are available from the Radio Products and Solutions
Organization offices listed in “Appendix B Replacement Parts Ordering”. While all of these items are
available from Motorola, most are standard shop equipment items, and any equivalent item capable
of the same performance may be substituted for the item listed.
NOTE: Do not place an order for the Programming Cable (PMKN4012A/PMKN4013B) as it is not compatible
with the APX 1000 radio.
4.3 Field Programming
This family of radios can be aligned and programmed in the field. This requires specific equipment
and special instructions. Refer to the online help in the Customer Programming Software (CPS) for
complete field programming information.
Table 4-2. Service Aids
Motorola Part
Number
Description Application
66012028001 Chassis Opener To disassemble chassis from housing
66012031001 Battery Adapter Used in place of battery to connect radio to an external power
supply.
5880384G68 SMA to BNC Adapter Adapts radio’s antenna port to BNC cabling of test equipment.
RVN5224_ Customer Programming
Software (CPS) and Tuner
Software
CPS allows customer-specific programming of modes and
features. Tuner software required to perform alignment of
radio parameters.
PMKN4012B Programming Cable To program the radio through Customer Programming
Software and Tuner Software.
PMKN4013C Programming/Service Cable To program and service the radio through Customer
Programming Software and Tuner Software.
RLN4460_ Portable Test Set For radio performance checks. Connects to radio’s universal
connector and allows remote switching and signal injection/
outputs for test equipment measurements.
