Motorola APX 7000 User Manual

•
The display shows <Device Friendly Name>
connect failed (if the connecting timer
expires).
If the PIN is correct but the profiles are not
supported, the display shows BT profiles not
supported. The display returns to Home screen.
Pairing the Authentication PIN with the Generated
Numeric PIN
Follow the procedure inSearching and Pairing the
Bluetooth Device on page 147 to search for available
Bluetooth devices. Start pairing with the
Authentication PIN by following the steps described
next.
1 or to the required device. Press the Menu
Select button directly below Sel to initiate pairing.
Your radio only supports HSP, DUN, PAN and
SPP Bluetooth profiles.
If successful, the display shows Pairing in
progress... followed by a randomly generated
numeric PIN, Compare PIN: XXXXXX.
If unsuccessful, the display shows
BT profiles
not supported. The display returns to Available
Dev screen.
2
Press Ok to continue pairing the radio and the
device.
The pairing process can be canceled by pressing
the Menu Select button below Cncl.
If successful, the display shows Pairing in
progress,<Device Friendly Name> paired,
Connecting in progress... followed by
<Device Friendly Name>connected. The
display returns to the Bluetooth feature screen.
If unsuccessful, one of the following scenarios will
occur:
•
The display shows <Device Friendly Name>
pair failed (if the PIN numbers are
different).
•
<Device Friendly Name> connect failed
(if the connection fails).
The display returns to Available Dev screen.
Advanced Features
151
English

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
