Motorola APX 7000 User Manual

Turning On the Radio
1 Rotate the On/Off/Volume Control Knob
clockwise until you hear a click.
• If the power-up test is successful, you see
momentary SELFTEST on the radio display,
followed by the Home screen.
• If the power-up test is unsuccessful, you see
Error XX/YY (XX/YY is an alphanumeric
code).
Note: If the radio fails to power-up after
repeating a few times, record the Error XX/YY
code and contact your dealer.
2 To turn off the radio, rotate the On/Off/Volume
Control Knob counterclockwise until you hear a
click.
Preparing Your Radio for Use
28
English

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
