Motorola ASTRO Digital Spectra Plus - Page 289

Schematics, Component Location Diagrams and Parts Lists: VOCON Section 7-31
6881076C25-E September 5, 2008
R259 &
R260
0662057A97 CHIP RES 100K OHMS 5%
R261 0662057A73 CHIP RES 10K OHMS 5%
R262 0662057A89 CHIP RES 47K OHMS 5%
R263 0662057A73 CHIP RES 10K OHMS 5%
R263 – NOT PLACED
R264 0662057A82 CHIP RES 24K OHMS 5%
R265 &
R266
0662057A97 CHIP RES 100K OHMS 5%
R267 0662057A73 CHIP RES 10K OHMS 5%
R268 0662057A97 CHIP RES 100K OHMS 5%
R269 0662057A85 CHIP RES 33K OHMS 5%
R272 0662057A73 CHIP RES 10K OHMS 5%
R273 0662057A97 CHIP RES 100K OHMS 5%
R274 thru
R282
0662057A85 CHIP RES 33K OHMS 5%
R283 – NOT PLACED
R284 0662057A97 CHIP RES 100K OHMS 5%
R285 thru
R287
– NOT PLACED
R289 thru
R307
– NOT PLACED
R402 0662057B12 CHIP RES 390K OHMS 5%
R403 – NOT PLACED
R404 0662057A73 CHIP RES 10K OHMS 5%
R405 0662057B22 CHIP RES 1.0 MEG OHMS
5%
R406 – NOT PLACED
R407 0662057A97 CHIP RES 100K OHMS 5%
R408 – NOT PLACED
R409 thru
R414
0662057A73 CHIP RES 10K OHMS 5%
R415 0662057A97 CHIP RES 100K OHMS 5%
R416 – NOT PLACED
R417 0662057A97 CHIP RES 100K OHMS 5%
R418 0662057A49 CHIP RES 1000 OHMS 5%
R419 0662057A73 CHIP RES 10K OHMS 5%
R420 0662057A97 CHIP RES 100K OHMS 5%
R421 &
R423
– NOT PLACED
R424 0662057A63 CHIP RES 3900 OHMS 5%
R425 0662057A69 CHIP RES 6800 OHMS 5%
R426 thru
R430
– NOT PLACED
R432 0662057A73 CHIP RES 10K OHMS 5%
R433 0662057A57 CHIP RES 2200 OHMS 5%
R434 – NOT PLACED
R435 0662057A73 CHIP RES 10K OHMS 5%
R436 thru
R438
– NOT PLACED
R477 thru
R480
– NOT PLACED
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
R481 0662057A97 CHIP RES 100K OHMS 5%
R482 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R483 thru
R485
0662057A97 CHIP RES 100K OHMS 5%
R490 thru
R492
– NOT PLACED
U201 5105625U33 IC 32KX8 EE EPROM 28
PIN TSOP
U202 5105662U54 HYBRID 32K X 8 SRAM
TESTED
U204 5105662U52 HYBRID CC HC11F1
U205 5105625U73 IC 256K X8 FLS ROM NIN
TSOP SD
U206 5105835U80 CC SLIC5 GLOBTOP DIE
91W30 86P
U208 – NOT PLACED
U210 5105625U73 IC 256K X8 FLS ROM NIN
TSOP SD
U211 5105279V65 IC
U401 – NOT PLACED
U402 &
U403
5105329V12 HYBRID CC BUMPED TEST
5596E99
U404 5105625U73 IC 256K X8 FLS ROM NIN
TSOP SD
U405 5105457W70 CC OMPAC DSP56001A
U406 5105457W19 CC ADSIC ABACUS/DSP
SUP/OMPAC
U407 5105492X73 IC 4.2V VOLTAGE
DETECTOR
U408 thru
U412
– NOT PLACED
U414 5105329V12 HYBRID CC BUMPED TEST
5596E99
U415 5105492X05 IC SNG HI SPD L-MOS OR
GATE
VR201 thru
VR203
4813830A15 DIODE 5.6V 5% 225MW
MMBZ5232B_
VR204 &
VR205
– NOT PLACED
VR206 4813830A31 DIODE 18V 5% 225MW
MMBZ5248B_
VR207 4813830A22 DIODE 9.1V 5% 225MW
MMBZ5239B_
VR208 4813830A24 DIODE 11V 5% 225MW
MMBZ5241B_
VR209 4813830A15 DIODE 5.6V 5% 225MW
MMBZ5232B_
VR210 – NOT PLACED
VR211 thru
VR214
4813830A15 DIODE 5.6V 5% 225MW
MMBZ5232B_
VR215 thru
VR223
– NOT PLACED
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
Y201 4805574W01 XTAL PRL RESONANCE
7.3728 MHZ
Y401 4805573W01 CRYSTAL SERIAL
RESONANCE
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
