Motorola ASTRO Digital Spectra Plus - Page 343

Schematics, Component Location Diagrams and Parts Lists: ASTRO Spectra Plus VOCON Section 7-85
6881076C25-E September 5, 2008
HLN6837E ASTRO Spectra Plus VOCON Electrical
Parts List
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C200 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C201 2113740F18 CAP,CHIP,4.3PF,.25PF+/-,
50V-DC
C202 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C205 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C206 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C207 2113743L17 CAP,CHIP,1000PF,+10%,-10%,
16V-DC
C208 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C209 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C210 2113743N26 CAP,CHIP,10PF,.5PF+/-,
16V-DC,0
C211 2113743L41 CAP,CHIP,.01UF,+10%,-10%,
16V-DC
C212 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C214 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C215 2113743L33 CAP,CHIP,4700PF,+10%,-10%,
16V-DC
C216 2113743L09 CAP,CHIP,470PF,+10%,-10%,
16V-DC
C217 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C218 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C219 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C220 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C223 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C224 2113743L09 CAP,CHIP,470PF,+10%,-10%,
16V-DC
C225 2113743L09 CAP,CHIP,470PF,+10%,-10%,
16V-DC
C226 2113743L09 CAP,CHIP,470PF,+10%,-10%,
16V-DC
C227 2113743L09 CAP,CHIP,470PF,+10%,-10%,
16V-DC
C228 2113743L09 CAP,CHIP,470PF,+10%,-10%,
16V-DC
C229 2113743L09 CAP,CHIP,470PF,+10%,-10%,
16V-DC
C300 2113928E01 CAP,CHIP,1UF,+10%,-10%,
10V-DC,
C301 2113743N50 CAP,CHIP,100PF,+5%,-5%,
16V-DC,
C302 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C303 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C304 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C305 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C306 – NOT PLACED
C307 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C308 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C309 2113743L09 CAP,CHIP,470PF,+10%,-10%,
16V-DC
C310 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C311 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C312 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C313 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C314 2113743N50 CAP,CHIP,100PF,+5%,-5%,
16V-DC,
C315 2113928E01 CAP,CHIP,1UF,+10%,-10%,
10V-DC,
C316 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C317 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C318 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C319 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C320 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C321 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C322 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C323 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C324 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C325 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C326 2113740F59 CAP,CHIP,220PF,+5%,-5%,
50V-DC,
C327 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C328 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C329 2113743N50 CAP,CHIP,100PF,+5%,-5%,
16V-DC,
C330 2113743L09 CAP,CHIP,470PF,+10%,-10%,
16V-DC
C331 2113743L09 CAP,CHIP,470PF,+10%,-10%,
16V-DC
C332 2113928E01 CAP,CHIP,1UF,+10%,-10%,
10V-DC,
C400 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C401 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C402 2113928E01 CAP,CHIP,1UF,+10%,-10%,
10V-DC,
C403 2113743N54 CAP,CHIP,150PF,+5%,-5%,
16V-DC,
C404 2113743N38 CAP,CHIP,33PF,+5%,-5%,
16V-DC,0
C405 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C406 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C407 2113743L41 CAP,CHIP,.01UF,+10%,-10%,
16V-DC
C415 2185802B01 CAP,CHIP,4.7UF,+10%,-10%,
10V-DC
C417 2185802B01 CAP,CHIP,4.7UF,+10%,-10%,
10V-DC
C420 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C422 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C423 2113743N28 CAP,CHIP,12PF,+5%,-5%,
16V-DC,0
C424 2113743N28 CAP,CHIP,12PF,+5%,-5%,
16V-DC,0
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C425 2185802B01 CAP,CHIP,4.7UF,+10%,-10%,
10V-DC
C427 2113743N50 CAP,CHIP,100PF,+5%,-5%,
16V-DC,
C428 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C429 2113743N54 CAP,CHIP,150PF,+5%,-5%,
16V-DC,
C430 2185802B01 CAP,CHIP,4.7UF,+10%,-10%,
10V-DC
C431 2113743E20 CAP,CHIP,.1UF,+10%,-10%,
16V-DC
C432 2113743L41 CAP,CHIP,.01UF,+10%,-10%,
16V-DC
C433 2113743E20 CAP,CHIP,.1UF,+10%,-10%,
16V-DC
C434 2185802B01 CAP,CHIP,4.7UF,+10%,-10%,
10V-DC
C435 2113743E20 CAP,CHIP,.1UF,+10%,-10%,
16V-DC
C436 2113743L41 CAP,CHIP,.01UF,+10%,-10%,
16V-DC
C437 2113743E20 CAP,CHIP,.1UF,+10%,-10%,
16V-DC
C438 2113743L41 CAP,CHIP,.01UF,+10%,-10%,
16V-DC
C439 2113743N30 CAP,CHIP,15PF,+5%,-5%,
16V-DC,0
C440 – NOT PLACED
C441 2113743E20 CAP,CHIP,.1UF,+10%,-10%,
16V-DC
C442 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C444 2113743N50 CAP,CHIP,100PF,+5%,-5%,
16V-DC,
C445 2185802B01 CAP,CHIP,4.7UF,+10%,-10%,
10V-DC
C446 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C447 2113743L41 CAP,CHIP,.01UF,+10%,-10%,
16V-DC
C448 2311049G01 CAP,FXD,150UF,+10%,-10%,
4V-DC,
C449 – NOT PLACED
C500 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C501 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
