Motorola ASTRO Digital Spectra Plus - Page 348

7-90 Schematics, Component Location Diagrams and Parts Lists: VCO Section
September 5, 2008 6881076C25-E
HLD6061D and HLD6062D Parts List
Notes:
1. Valid in HLD6061D only.
2. Valid in HLD6062D only.
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C3647 thru
C3652
2113740B65 CAP CHIP REEL CL1 +/-30
470
C3653 2113740B73
2113740B65
CAP CHIP REEL CL1 +/-30
1000
1
CAP CHIP REEL CL1 +/-30
470
2
C3654 2113740B69
2111078B59
CAP CHIP REEL CL1 +/-30
680
1
CAP CHIP RF 470 5 NPO
100V
2
C3655 &
C3656
2111078B59 CAP CHIP RF 470 5 NPO
100V
C3657 2111078B59
2113740B65
CAP CHIP RF 470 5 NPO
100V
1
CAP CHIP REEL CL1 +/-30
470
2
C3658 2111078B59
2113740B65
CAP CHIP RF 470 5 NPO
100V
1
CAP CHIP REEL CL1 +/-30
470
2
C3659 2113740B11
2113740B09
CAP CHIP REEL CL1 +/-30
2.7
1
CAP CHIP REEL CL1 +/-30
2.2
2
C3660 2113740B11 CAP CHIP REEL CL1 +/-30
2.7
C3661 2113740B19 CAP CHIP REEL CL1 +/-30
5.6
C3662 &
C3663
2113740B65 CAP CHIP REEL CL1 +/-30
470
C3664 2113741N45 CAP CHIP CL2 X7R 10%
10000
C3665 2111078B59
2111078B31
CAP CHIP RF 470 5 NPO
100V
1
CAP CHIP RF 36 5 NPO
100V
2
C3666 2111078B23 CAP CHIP RF 24 5 NPO
100V
C3667 2111078B31 CAP CHIP RF 36 5 NPO
100V
C3668 2113741N45 CAP CHIP CL2 X7R 10%
10000
C3669 2111078B05 CAP CHIP RF 4.7 .25 NPO
100V
C3670 2111078B11 CAP CHIP RF 8.2 .5 NPO
100V
C3671 2113740B65 CAP CHIP REEL CL1 +/-30
470
C3672 2113740B05 CAP CHIP REEL CL1 +/-30
1.5
C3680 2113740B01
–
CAP CHIP REEL CL1 +/-30
1.0
1
NOT PLACED
2
C3681 2113740B65 CAP CHIP REEL CL1 +/-30
470
C3682 2113741N45 CAP CHIP CL2 X7R 10%
10000
CR3640 4805656W04 DIODE SOT 23 PIN
CR3641 &
CR3642
4880142L01 DIODE PIN SOT 23 MMBV
3401
CR3643 4880006E09 DIODE VARACTOR
MMBV109 350MW
CR3644 &
CR3645
4880006E13 DIODE VAR SI SMBV1050
350MW
CR3646 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
JU3601 –
0611077A01
NOT PLACED
1
RES CHIP JUMPER
2
JU3602 0611077A01
–
RES CHIP JUMPER
1
NOT PLACED
2
L3640 thru
L3647
2480140E01 INDUCTOR CHIP 1.2 UH
L3648 2405452C87 COIL CHIP INDUCTOR 39 5
L3649 &
L3650
2480140E01 INDUCTOR CHIP 1.2 UH
L3652 2405452C87 COIL CHIP INDUCTOR 39 5
MP3640
thru
MP3653
0780299L01 FRAME LEAD J STRAP
Q3644 4880141L06 TSTR NC MOS FET SOT23
TGR MMBF
Q3645 4813827A03 TSTR NPN SML SIG
MMBR901LT1 7X
R3650 0611077A26 RES CHIP 10 5 1/8W
R3651 &
R3652
0611077B07 RES CHIP 22K 5 1/8W
R3653 0611077B03 RES CHIP 15K 5 1/8W
R3654 0611077B23
–
RES CHIP 100K 5 1/8W
1
NOT PLACED
2
R3655 0611077B07 RES CHIP 22K 5 1/8W
R3656 0611077A50 RES CHIP 100 5 1/8W
R3657 0611077A66 RES CHIP 470 5 1/8W
RT3640 0680149M01 THERMISTOR CHIP 470
OHMS
1280954T43 SPECTRA VHF VCO
ASSEMBLY
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
