Motorola ASTRO Digital Spectra Plus - Page 411

Schematics, Component Location Diagrams and Parts Lists: Power Amplifier Section 7-153
6881076C25-E September 5, 2008
Q5804 4880141L01 TSTR PNP SOT23 LO PROFILE
TAPE
Q5805 &
Q5806
4880141L02 TSTR NPN SOT23 LO PROFILE
TAPE
Q5850 4880225C27 TSTR RF MRF654F IN CS12 PKG
Q5851 4880225C30 TSTR RF 14W/50W UHF .5 CQ
Q5875 4880225C29 TSTR RF MRF658 IN FLANGE
PKG
Q5876 4880225C29 TSTR RF MRF658 IN FLANGE
PKG
R5801 0611077A30 RES CHIP 15 5 1/8W
R5802 0611077A74 RES CHIP 1000 5 1/8
R5803 0611077A82 RES CHIP 2200 5 1/8
R5805 0611077A26 RES CHIP 10 5 1/8W
R5806 0611077A50 RES CHIP 100 5 1/8W
R5807 0611077A82 RES CHIP 2200 5 1/8
R5808 0611077A90 RES CHIP 4700 5 1/8
R5809 0611077A78 RES CHIP 1500 5 1/8
R5810 0611077A26 RES CHIP 10 5 1/8W
R5811 0611077A74 RES CHIP 1000 5 1/8
R5812 0611077A01 RES CHIP JUMPER
R5813 &
R5814
– NOT PLACED
R5816 0611077A80 RES CHIP 1800 5 1/8
R5817 0611077A74 RES CHIP 1000 5 1/8
R5818 0611077A62 RES CHIP 330 5 1/8W
R5819 0611077A86 RES CHIP 3300 5 1/8
R5820 0611077B01 RES CHIP 12K 5 1/8W
R5821 0611077A90 RES CHIP 4700 5 1/8
R5822 0611077A74 RES CHIP 1000 5 1/8
R5823 0611077A98 RES CHIP 10K 5 1/8W
R5824 0611077A90 RES CHIP 4700 5 1/8
R5825 0611077B05 RES CHIP 18K 5 1/8W
R5826 0611077A68 RES CHIP 560 5 1/8W
R5827 0611077A50 RES CHIP 100 5 1/8W
R5828 0611077B15 RES CHIP 47K 5 1/8W
R5843 0611077B07 RES CHIP 22K 5 1/8W
R5850 &
R5851
0611077A10 RES CHIP 2.2 5 1/8W
R5853 &
R5854
0611077A10 RES CHIP 2.2 5 1/8W
R5855 0611077A74 RES CHIP 1000 5 1/8
R5857 0611077A82 RES CHIP 2200 5 1/8
R5858 0611077A74 RES CHIP 1000 5 1/8
R5859 0611077A50 RES CHIP 100 5 1/8W
R5875 1780165C02 RES SHUNT
R5876 &
R5877
0611077A10 RES CHIP 2.2 5 1/8W
R5878 0680194M01 RES 10 OHMS 5% 1W
R5879 &
R5880
0680194M13 RES 33 OHMS 5% 1W
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R5881 &
R5882
0680194M01 RES 10 OHMS 5% 1W
R5900 0680194M18 RES 51 OHMS 5% 1W
R5901 0680194M01 RES 10 OHMS 5% 1W
R5904 0611077A50 RES CHIP 100 5 1/8W
R5905 0611077A60 RES CHIP 270 5 1/8W
R5906 0611077A74 RES CHIP 1000 5 1/8
R5907 0611077B11 RES CHIP 33K 5 1/8W
R5908 &
R5909
0611077A54 RES CHIP 150 5 1/8W
R5910 0611077B23 RES CHIP 100K 5 1/8W
R5911 0611077A74 RES CHIP 1000 5 1/8
R5912 &
R5913
0611077B47 RES CHIP 1 MEG 5 1/8W
R5914 0611077A90 RES CHIP 4700 5 1/8
R5915 0611077A26 RES CHIP 10 5 1/8W
R5916 0611077A66 RES CHIP 470 5 1/8W
R5917 0680194M01 RES 10 OHMS 5% 1W
RT5875
&
RT5904
0680149M02 THERMISTOR CHIP 100K OHM
Z1 4813830A14 DIODE 5.1V 5% 225MW
MMBZ5231B_
Z2 – NOT PLACED
2280128P01 PIN POLARIZING
8480110P05 BD CKT PA UHF
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
