Motorola ASTRO Digital Spectra User Manual

Schematics, Component Location Diagrams and Parts Lists: RF Section 7-11
6881076C25-E September 5, 2008
HRN4009C/HRN6014C VHF RF Board Electrical Parts List
1. For optimum performance, order replacement diodes, transistors, and circuit
modules by Motorola part number only.
2. When ordering crystals, specify carrier frequency, crystal frequency, crystal
type number, and Motorola part number.
3. Part value notations:
p=10
-12
m=10
-3
n=10
-9
k=10
3
µ=10
-6
M=10
6
4. ITEM refers to the component reference designator.
5. The RF Board Kits use a 6-layer printed circuit board.
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
CAPACITOR, Fixed:
unless otherwise stated
C300 2113740B65 470pF
C301, 302 2113741N45 .01µF
C303 – Not Placed
C304 2311049J26 10pF
C305 2113741B41 6800pF
C306 2113740B69 680pF
C307 2113741N45 .01µF
C308 2311049J26 10pF
C309 2113741N57 .033µF
C310 2113741N69 0.1µF
C311 2311049J26 10pF
C312 – Not Placed
C313 2113740B65 470pF
C314 2113741N69 0.1µF
C315 2113740B73 1000pF
C316 2113743G21 1.0µF
C317 2311049J26 10pF
C318 2113740B31 18pF
C319 2113741N45 .01µF
C320 2113741N61 .047µF
C321 2113741N21 1000pF
C322, 323 – Not Placed
C324 2113741N69 0.1µF
C325, 326 2113741N45 .01µF
C327 2311049J26 10pF
C329 2113741N69 0.1µF
C330 2113740B49 100pF
C332 thru 334 2113740B49 100pF
C336, 337 2113740B49 100pF
C339 2113740B49 100pF
C341 2113740B49 100pF
C343 2113740B27 12pF
C345 2113741N69 0.1µF
C350 2113741N45 .01µF
C351 – Not Placed
C352 2113741N45 .01µF
C353 2113740B15 3.9pF
C354, 355 2113741N69 0.1µF
C357 2113740B17 4.7pF
C358 2113741N69 0.1µF
C600 2113740B49 100pF
C601 2113740B34 24pF
C604 2113741N21 1000pF
C605 2380090M06 10pF
C606, 607 2311049J26 10pF
C608 2380090M06 10pF
C609 2113741N69 0.1µF
C610 2113741N45 .01µF
C611 – Not Placed
C612 2113741N69 0.1µF
C613 2113741N45 .01µF
C614 2113740B31 18pF
C615 2113740B39 39pF
C616 2113741N45 .01µF
C617 thru 619 2113741N69 0.1µF
C620 2113741N45 .01µF
C621 2113740B25 10pF
C622 2113741N21 1000pF
C623 0880027B09 100pF
C624 2113741N45 .01µF
C625 2113741D28 0.22µF
C626 2113740B76 1500pF
C627 thru 629 2113741N45 .01µF
C630 211374 0B73 1000pF
C631 2311049J07 3.3pF
C632 2380090M06 10pF
C633 2311049J26 10pF
C634 2113740B76 1500pF
C635 2380090M06 10pF
C636 2380090M07 47pF
C637 2113741N69 0.1µF
C638 2113741N45 .01µF
C639 2113741N69 0.1µF
C641 2113740B01 1.0pF
C642 2113741N69 0.1µF
C644 2113741N69 0.1µF
C645 2113740B49 100pF
C646 2113743G21 1.0µF
C647 2113741N69 0.1µF
C648 thru 650 – Not Placed
C651 2113740B49 100pF
C652 – Not Placed
C653 2113740B49 100pF
C654 2113740B76 1500pF
C656 2113741N69 0.1µF
C657 2113740B27 12pF
C658 2113741N45 .01µF
C659 2113740B27 12pF
C660 2113741N69 0.1µF
C664 2113741N45 .01µF
C665 2113740B27 12pF
C670 2113740B79 2000pF
DIODE: See Note 1.
CR301 4880006E09 Varactor
CR350 – Not Placed
CR351 4882958R39 3.3V
CR352 4880154K03 Dual; Shottky
CR601 4880006E09 Varactor
CR602, 603 4811058B11
CR605 – Not Placed
CR606 4813830A28
CORE:
E301 2680003M03 Ferrite Bead
E302 2680004M03 Ferrite Bead
E602 2680006M02 Ferrite Bead
FILTER: See Note 2.
FL300, 301 9185128U02 LC; 450kHz
JACK:
J350 0980110M01 Receptacle, Coaxial
J500 0980104M02 Receptacle, Bottom-Entry
J601 0980103N02 Sockets, 12-Position
J602 – Not Placed
JUMPER:
JU300, 301 0611077A01 0W
JU351 0611077A01 0W
JU352 – Not Placed
JU601 0611077A01 0W
ITEM
MOTOROLA
PART N UMBER
DESCRIPTION
JU604 thru 606 – Not Placed
JU607 0611077A01 0W
JU608 – Not Placed
JU609 0611077A01 0W
JU611 – Not Placed
JU612 0611077A01 0W
JU613 thru 615 – Not Placed
JU617 0611077A01 0W
JU618 thru 620 – Not Placed
COIL, RF:
unless otherwise stated
L302 – Not Placed
L303 2411087A32 3.3µH
L304 2480140E16 10µH
L351 2480140E11 360nH
L352, 353 2405452C78 295nH
L354 2480140E16 10µH
L600 2480140E06 130nH
L603 – Not Placed
L604 2480140E01 1.2µH
L605 – Not Placed
L608 2480140E16 10µH
L610, 611 2480140E01 1.2µH
TRANSISTOR: See Note 1.
Q350 4802000P02 NPN
Q351 thru 353 – Not Placed
Q602, 603 4805128M27 SOT89
Q606 4884235R02 SOT
Q607 4880182D48 PNP
Q608 4880141L01 PNP; SOT23
Q609, 610 4880141L02 NPN; SOT23
Q670 4805218N11 SOT
RESISTOR: Ohms ±5%;
1/8W unless otherwise stated
R300 0611077A98 10k
R301 0611077A19 5.1
R302 0611077A36 27
R303 0611077B33 270k
R307, 308 0611077A46 68
R311, R312 0611077A01 0
R313 0611077A38 33
R314 0611077B09 27k
R315 0611077A98 10k
R316 0611077A94 6.8k
R317 0611077A43 51
R318 0611077A01 0
R319 – Not Placed
R320 0611077A26 10
R325 – Not Placed
R350 0611077A52 120
R351 0611077A26 10
R353 0611077A78 1.5k
R354 0611077A28 12
R355 0611077A01 0
R356 0611077A38 33
R357 0611077A98 10k
R358 0611077A10 2.2
R602 0611077A43 51
R607 0611077A74 1k
R608 0611077A98 10k
R609 0611077A62 330
R610 0611077A43 51
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R611 0611077B31 220k
R612 – Not Placed
R613 0611077B11 33k
R614 0611077A90 4.7k
R615 0611077B47 1M
R616 0611077B07 22k
R617 0611077B11 33k
R618 0611077A28 12
R620 0611077A74 1k
R622 0611077A74 1k
R623 0611077A26 10
R624 0611077A98 10k
R625 0611077B07 22k
R626 0611077B23 100k
R627 0611077A90 4.7k
R628 thru 630 0611077A78 1.5k
R631 0611077B47 1M
R633 0611077B21 82k
R634 1880273N01 Potentiometer
R635 0611077B23 100k
R637 0611077B31 220k
R638, 639 0611077A98 10k
R640 0611077B31 220k
R641 0611077A43 51
R642 0611077A98 10k
R645 0611077B47 1M
R646, 647 0611077A98 10k
R653 0611077B11 33k
R670 0611077A90 4.7k
INTEGRATED CIRCUIT
MODULE: See Note 1.
U301 5105835U90 Hybrid, ABACUS
U302 5105469E90 5V Regulator
U600 5180291B09 Reference Oscillator
U601 5180057S09 Prescaler
U602 5180057S10 Synthesizer
CRYSTAL: See Note 2.
Y350 9180084M01 109.65MHz
MISCELLANEOUS:
2605256X01 Shield, Filter
7580094M06 Pad, VF Shock
8485865B01 Circuit Board
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
LAYER 1 (L1)
LAYER 2 (L2)
LAYER 3 (L3)
LAYER 4 (L4)
INNER LAYERS
LAYER 5 (L5)
LAYER 6 (L6)
MAEPF-18827-A
SIDE 1
SIDE 2
6-LAYER CIRCUIT BOARD DETAIL VIEWING
COPPER STEPS IN PROPER LAYER SEQUENCE
