Motorola ASTRO Digital Spectra User Manual

Schematics, Component Location Diagrams and Parts Lists: RF Section 7-15
6881076C25-E September 5, 2008
HRN4009E and HRN6014D VHF RF Board, HRN6010D
and HRN6020C UHF RF Board, and HRN6019C 800
MHz RF Board Parts Lists
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
CAPACITOR, Fixed:
unless otherwise stated
C300 2113740B65 470pF
C301, 302 2113741N45 .01µF
C303 – Not Placed
C304 2311049J26 10pF
C305 2113741B41 6800pF
C306 2113740B69 680pF
C307 2113741N45 .01µF
C308 2311049J26 10pF
C309 2113741N57 .033µF
C310 2113741N69 0.1µF
C311 2311049J26 10pF
C312, 313 – Not Placed
C314 2113741N69 0.1µF
C315 2113740B73 1000pF
C316 2311049A37 1.0µF
C317 2311049J26 10pF
C318 2113740B31 18pF
C319 2113741N45 .01µF
C320 2113741N61 .047µF
C321 2113741N21 1000pF
C322, 323 2113741N69 0.1µF (Placed on UHF Bd Only)
C324 2113741N69 0.1µF
C325, 326 2113741N45 .01µF
C327 2311049J26 10pF
C329 2113741N69 0.1µF
C330 2113740B49 100pF
C332, 333 2113740B49 100pF
C334 2113740B49 100pF/Not Placed (see Note 6)
C336, 337 2113740B49 100pF
C339 2113740B49 100pF
C341 2113740B49 100pF (Placed on VHF Bd Only)
C343 2113740B27 12pF
C345 2113741N69 0.1µF
C350 2113740B09 2.2pF
C351 2113741N69 0.1µF (Placed on UHF Bd Only)
C352 2113741N69 0.1µF
C353 2113740B13 3.3pF
C354, 355 2113741N69 0.1µF
C357 2113740B13 3.3pF
C358 2113741N69 0.1µF
C359 2113740B19 5.6pF
C360 2113741N69 0.1µF
C361, 362 – Not Placed
C363 2113740B07 1.8pF (Placed on VHF and
800MHz Bds Only)
C364 2113740B11 2.7pF (VHF Bd)
or 2113740B19 5.6pF (UHF and 800MHz Bds)
C365, 366 2113741N69 0.1µF
C600 2113740B49 100pF
C601 2113740B34 24pF
C604 2113741N21 1000pF
C605 2380090M06 10pF
C606, 607 2311049J26 10pF
C608 2380090M06 10pF
C609 2113741N69 0.1µF
C610 2113741N45 .01µF
C611 – Not Placed
C612 2113741N69 0.1µF
C613 2113741N45 .01µF
C614 2113740B31 18pF
C615 2113740B39 39pF
C616 2113741N45 .01µF
C617 thru 619 2113741N69 0.1µF
C620 2113741N45 .01µF
C621 2113740B25 10pF
C622 2113741N21 1000pF
C623 0880027B09 100pF
C624 2113741N45 .01µF
C625 2113741D28 0.22µF
C626 2113741N45 .01µF (Placed on UHF Bd Only)
C627 thru 629 2113741N45 .01µF
C630 2113740B76 1500pF
C631 2311049J07 3.3pF
C632 2380090M06 10pF
C633 2311049J26 10pF
C634 2113740B76 1500pF
C635 2380090M06 10pF
C636 2380090M07 47pF
C637 2113741N69 0.1µF
C638 2113741N45 .01µF
C639 2113741N69 0.1µF
C641 2113740B01 1.0pF
C642 2113741N69 0.1µF
C644 2113741N69 0.1µF
C645 2113741N45 .01µF
C646 2311049A37 1.0µF
C647 2113741N69 0.1µF
C648 thru 650 – Not Placed
C651 2113740B49 100pF
C652 2113740B49 100pF (Placed on UHF Bd Only)
C653 2113740B49 100pF
C654 2113741N45 .01µF (VHF and 800MHz Bds)
or – Not Placed (UHF Bd)
C656 2113741N69 0.1µF
C657 2113740B27 12pF
C658 2113741N45 .01µF
C659 2113740B27 12pF
C660 2113741N69 0.1µF
C664 2113741N45 .01µF
C665 2113740B27 12pF
C670 2113740B79 2000pF (Placed on VHF Bd Only)
DIODE: See Note 1.
CR301 4880006E09 Varactor
CR350 4880140L20 (Placed on UHF Bd Only)
CR352 4880154K03 Dual; Shottky (Placed on VHF Bd
Only)
CR353 4880154K03 Dual; Shottky
CR601 4880006E09 Varactor
CR602, 603 4811058B11
CR605 – Not Placed
CR606 4813830A28
CORE:
E301 2680006M02 Ferrite Bead
E302 2680004M03 Ferrite Bead
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
E303 2605261V01 Ferrite Bead (Placed on 800MHz
Bd Only)
E602 2680006M02 Ferrite Bead
FILTER: See Note 2.
FL300, 301 9185128U02 LC; 450kHz
FL350, 351 4885230C01 Crystal, 109.65 MHz
JACK:
J350 0980110M01 Receptacle, Coaxial
J500 0980104M02 Receptacle, Bottom-Entry
J601 0980103N02 Sockets, 12-Position
J602 – Not Placed
JUMPER:
JU300, 301 0611077A01 0Ω
JU351 0611077A01 0Ω (Placed on VHF and 800MHz
Bds Only)
JU352 0611077A01 0Ω (Placed on UHF Bd Only)
JU601 0611077A01 0Ω
JU604 – Not Placed
JU605 0611077A01 0Ω (Placed on UHF and 800MHz
Bds Only)
JU606 0611077A01 0Ω (Placed on UHF Bd Only)
JU607 0611077A01 0Ω (Placed on VHF and 800MHz
Bds Only)
JU608 0611077A01 0Ω (Placed on UHF Bd Only)
JU609 0611077A01 0Ω (Placed on VHF and 800MHz
Bds Only)
JU611 – Not Placed
JU612 0611077A01 0Ω (Placed on VHF Bd Only)
JU613 0611077A01 0Ω (Placed on UHF Bd Only)
JU614 0611077A01 0Ω (Placed on 800MHz Bd Only)
JU615 – Not Placed
JU617 0611077A01 0Ω (Placed on VHF Bd Only)
JU618 0611077A01 0Ω (Placed on UHF Bd Only)
JU619 0611077A01 0Ω (Placed on 800MHz Bd Only)
JU620 – Not Placed
COIL, RF:
unless otherwise stated
L302 – Not Placed
L303 2411087A32 3.3µH
L304 2480140E16 10µH
L350 2405423A12 470nH
L351 2405423A11 390nH (VHF and UHF Bds)
or 2405452C90 400nH (800MHz Bd)
L352 2405423A12 470nH
L353 2405423A11 390nH (VHF Bd)
or 2405423A12 470nH (UHF and 800MHz Bds)
L354 2480140E16 10µH
L600 2480140E06 130nH
L603 – Not Placed
L604 2480140E01 1.2µH
L605 – Not Placed
L608 2480140E16 10µH
L610, 611 2480140E01 1.2µH
TRANSISTOR: See Note 1.
Q350 4802000P02 NPN
Q351 4880052M01 NPN; Darlington (Placed on UHF
Bd Only)
Q352 4884235R02 SOT (Placed on UHF Bd Only)
ITEM
MOTOROLA
PART N UMBER
DESCRIPTION
Q353 4880048M01 NPN (Placed on UHF Bd Only)
Q354 4802000P02 NPN
Q602, 603 4805128M27 SOT89
Q606 4884235R02 SOT
Q607 4880182D48 PNP
Q608 4880141L01 PNP; SOT23
Q609, 610 4880141L02 NPN; SOT23
Q670 4805218N11 SOT (Placed on VHF Bd Only)
RESISTOR: Ohms ±5%;
1/8W unless otherwise stated
R300 0611077A98 10k
R301 0611077A19 5.1
R302 0611077A36 27
R303 0611077B33 270k
R307, 308 0611077A46 68
R311 0611077A01 0
R312 0611077A01 0 (Placed on UHF and 800MHz
Bds Only)
R313 0611077A38 33 (VHF Bd)
or 0611077A74 1k (UHF and 800MHz Bds)
R314 0611077B09 27k
R315 0611077A98 10k
R316 0611077A94 6.8k
R317 0611077A43 51
R318 0611077A01 0
R319 – Not Placed
R320 0611077A26 10
R325 – Not Placed
R350 0611077A58 220
R351 0611077A36 27
R353 0611077A78 1.5k
R354 0611077A28 12
R355 0611077A01 0 (VHF and 800MHz Bds)
or 0611077A98 10k (UHF Bd)
R356 0611077A58 220
R357 0611077A98 10k (Placed on VHF Bd Only)
R358 0611077A10 2.2 (Placed on VHF and 800MHz
Bds Only)
R360 0611077A58 220 (VHF Bd)
or 0611077A52 120 (UHF and 800MHz Bds)
R361 0611077A32 18 (VHF Bd)
or 0611077A36 27 (UHF and 800MHz Bds)
R363 0611077A78 1.5k
R364 0611077A28 12
R366 0611077A36 27
R602 0611077A43 51
R607 0611077A74 1k
R608 0611077A98 10k
R609 0611077A62 330
R610 0611077A43 51
R611 0611077B31 220k
R612 0611077B31 220k (Placed on UHF Bd only)
R613 0611077B11 33k
R614 0611077A90 4.7k
R615 0611077B47 1M
R616 0611077B07 22k (VHF Bd)
or 0611077A98 10k (UHF and 800MHz Bds)
R617 0611077B11 33k
R618 0611077A28 12
R620 0611077A74 1k
R622 0611077A74 1k
ITEM
MOTOROLA
PART N U M BER
DESCRIPTION
