Schematics, Component Location Diagrams and Parts Lists: RF Section 7-23
6881076C25-E September 5, 2008
Command Boards Reference Designator and Part
Number Comparison Chart
The following table lists those reference designators
common to the various command board kits and the part
numbers assigned to those designators for each kit and
version.
HLN5558H/J, HLN6529H, HLN6560J, and HLN6562J
Parts List
Ref Des
HLN5558J
Part Number
HLN6529H
Part Number
HLN6560J
Part Number
HLN6562J
Part Number
C571 2105285X01 NOT PLACED 2105285X01 2105285X01
JU500 NOT PLACED NOT PLACED 0611077A01 0611077A01
JU513 NOT PLACED NOT PLACED 0611077A01 0611077A01
JU518 0611077A01 0611077A01 NOT PLACED NOT PLACED
JU519 0611077A01 0611077A01 NOT PLACED 0611077A01
JU521 0611077A01 0611077A01 NOT PLACED NOT PLACED
JU528 NOT PLACED NOT PLACED 0611077A01 NOT PLACED
JU532 NOT PLACED NOT PLACED NOT PLACED 0611077A01
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
BT001 – NOT PLACED
C401 2113741N69 CAP CHIP CL2 X7R 10%
100000
C402 2113741N69 CAP CHIP CL2 X7R 10%
100000
C404 2113741N45 CAP CHIP CL2 X7R 10%
10000
C405 2113743G21 CER CHIP CAP 1.0 UF
C406 2113743G24 CAP CHIP 2.2 UF 16V +80-
20%
C408 2113741N45 CAP CHIP CL2 X7R 10%
10000
C412 2113741N69 CAP CHIP CL2 X7R 10%
100000
C413 2113740B57 CAP CHIP REEL CL1 +/-30
220
C416 2113743G24 CAP CHIP 2.2 UF 16V +80-
20%
C418 2113741N69 CAP CHIP CL2 X7R 10%
100000
C420 2113743G24 CAP CHIP 2.2 UF 16V +80-
20%
C421 2113743G24 CAP CHIP 2.2 UF 16V +80-
20%
C434 2113741N69 CAP CHIP CL2 X7R 10%
100000
C436 2311049J09 CAP TANT CHIP 3.3 10 35
C437 2311049J26 CAP TANT CHIP 10 20 16
C438 2311049J09 CAP TANT CHIP 3.3 10 35
C451 & C452 2113743G21 CER CHIP CAP 1.0 UF
C453 2113741N69 CAP CHIP CL2 X7R 10%
100000
C454 2113741N69 CAP CHIP CL2 X7R 10%
100000
C455 2113740B57 CAP CHIP REEL CL1 +/-30
220
C456 2380090M24 CAP ALU 10 20 50V SURF
MT
C458 2113741N69 CAP CHIP CL2 X7R 10%
100000
C459 thru
C461
2113743G24 CAP CHIP 2.2 UF 16V +80-
20%
C462 2113741B51 CAP CHIP CL2 X7R REEL
18000
C463 2113740B59 CAP CHIP REEL CL1 +/-30
270
C464 2113741N45 CAP CHIP CL2 X7R 10%
10000
C465
– NOT PLACED
C466 2113743F14 CAP CHIP .470UF +80 -
20% Y5V
C467
– NOT PLACED
C468 2113743F08 CER CHIP CAP .220UF
C476, C478
& C480
2113740B65 CAP CHIP REEL CL1 +/-30
470
C481 2113741N21 CAP CHIP CL2 X7R 10%
1000
C482 2311049A28 CAP TANT CHIP 100UF 6V
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C500 & C501 2113743G24 CAP CHIP 2.2 UF 16V +80-
20%
C502 2113740B36 CAP CHIP REEL CL1 +/-30
30
C503
– NOT PLACED
C504 2113741N21 CAP CHIP CL2 X7R 10%
1000
C505 2311049A40 CAP TANT CHIP 2.2 10 10
C506 & C507 2113743G24 CAP CHIP 2.2 UF 16V +80-
20%
C508 2113743G21 CER CHIP CAP 1.0 UF
C509 2113743G24 CAP CHIP 2.2 UF 16V +80-
20%
C510 2113741N69 CAP CHIP CL2 X7R 10%
100000
C511 2113743F16 CAP CHIP 1.0 UF 16V +80-
20%
C512 2311049A40 CAP TANT CHIP 2.2 10 10
C513 2311049A03 CAP TANT CHIP A/P .22
10 35
C524 2113741N45 CAP CHIP CL2 X7R 10%
10000
C527 2113741N69 CAP CHIP CL2 X7R 10%
100000
C535 2113741N45 CAP CHIP CL2 X7R 10%
10000
C548 2113743G21 CER CHIP CAP 1.0 UF
C549 2113741N69 CAP CHIP CL2 X7R 10%
100000
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C554 2113740B65 CAP CHIP REEL CL1 +/-30
470
C560 2311049A40 CAP TANT CHIP 2.2 10 10
C561 2113740B65 CAP CHIP REEL CL1 +/-30
470
C562 2113740B65
–
CAP CHIP REEL CL1 +/-30
470
1 and 5
NOT PLACED
2, 3, and 4
C563 2113740B65 CAP CHIP REEL CL1 +/-30
470
C564 2113740B65 CAP CHIP REEL CL1 +/-30
470
C565 2113740B65 CAP CHIP REEL CL1 +/-30
470
C569 2113740B65 CAP CHIP REEL CL1 +/-30
470
C570 2113740B65 CAP CHIP REEL CL1 +/-30
470
C571 2105285X01
–
CAP GOLD F SERIES (.47
FARAD)
1, 2, 4, and 5
NOT PLACED
3
C572 2113740B65 CAP CHIP REEL CL1 +/-30
470
C575 2113740B65 CAP CHIP REEL CL1 +/-30
470
C576 2113740B65 CAP CHIP REEL CL1 +/-30
470
C577 2113740B65 CAP CHIP REEL CL1 +/-30
470
C580 2113741N69 CAP CHIP CL2 X7R 10%
100000
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
