Schematics, Component Location Diagrams and Parts Lists: ASTRO Spectra Plus VOCON Section 7-61
6881076C25-E September 5, 2008
R223 0662057M98 RES. CHIP 10K 5% 20X40
R224 0662057N23 RES. CHIP 100K 5% 20X40
R226 0662057N10 RES. CHIP 30K 5% 20X40
R229 0662057N23 RES. CHIP 100K 5% 20X40
R230 0662057N23 RES. CHIP 100K 5% 20X40
R231 0662057N10 RES. CHIP 30K 5% 20X40
R232 0662057M98 RES. CHIP 10K 5% 20X40
R234 0662057M50 RES. CHIP 100 5% 20X40
R240 0662057M86 RES. CHIP 3300 5X 20X40
R241 – NOT PLACED
R242 0662057M64 RES. CHIP 390 5% 20X40
R243 – NOT PLACED
R245 -
R249
– NOT PLACED
R250 0662057M90 RES. CHIP 4700 5% 20X40
R301 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R303 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R304 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R306 – NOT PLACED
R307 0662057N15 RES. CHIP 47K 5% 20X40
R308 0662057N15 RES. CHIP 47K 5% 20X40
R309 NOT PLACED
R310 0662057N15 RES. CHIP 47K 5% 20X40
R311 0662057M98 RES. CHIP 10K 5% 20X40
R313 0662057M78 RES. CHIP 1500 5% 20X40
R314 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R315 0662057N15 RES. CHIP 47K 5% 20X40
R316 0662057M34 RES. CHIP 22 5% 20X40
R317 0662057M34 RES. CHIP 22 5% 20X40
R318 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R320 -
R321
– NOT PLACED
R322 0662057N23 RES. CHIP 100K 5% 20X40
R323 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R325 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R329 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R331 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R332 0662057M98 RES. CHIP 10K 5% 20X40
R333 0662057N15 RES. CHIP 47K 5% 20X40
R340 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R341 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R342 – NOT PLACED
R343 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R344 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R345 0662057M74 RES. CHIP 1000 5% 20X40
R346 0662057N15 RES. CHIP 47K 5% 20X40
R347 0662057N15 RES. CHIP 47K 5% 20X40
R348 – NOT PLACED
R349 0662057N15 RES. CHIP 47K 5% 20X40
R400 0662057M86 RES. CHIP 3300 5X 20X40
R401 0662057M86 RES. CHIP 3300 5X 20X40
R402 0662057N23 RES. CHIP 100K 5% 20X40
R403 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R404 0662057M91 RES CHIP 5100 5% 20X40
R405 0662057M82 RES. CHIP 2200 5% 20X40
R406 0662057N23 RES. CHIP 100K 5% 20X40
R407 0662057M98 RES. CHIP 10K 5% 20X40
R408 0662057N05 RES. CHIP 18K 5% 20X40
R409 0662057N23 RES. CHIP 100K 5% 20X40
R410 0662057M98 RES. CHIP 10K 5% 20X40
R416 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R419 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R420 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R421 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R425 0662057B46 CHIP RES 10.0 MEG OHMS 5%
R426 0662057N39 RES. CHIP 470K 5% 20X40
R427 0662057B46 CHIP RES 10.0 MEG OHMS 5%
R428 0662057M50 RES. CHIP 100 5% 20X40
R429 – NOT PLACED
R430 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R434 0662057M81 RES. CHIP 2000 5% 20X40
R435 0662057M74 RES. CHIP 1000 5% 20X40
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R436 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R437 0662057N07 RES. CHIP 22K 5% 20X40
R438 0662057N07 RES. CHIP 22K 5% 20X40
R441 0662057N39 RES. CHIP 470K 5% 20X40
R442 0662057N39 RES. CHIP 470K 5% 20X40
R443 0662057B46 CHIP RES 10.0 MEG OHMS 5%
R451 0662057N13 RES. CHIP 39K 5% 20X40
R452 0662057N06 RES. CHIP 20K 5% 20X40
R454 0662057N11 RES. CHIP 33K 5% 20X40
R455 0662057N15 RES. CHIP 47K 5% 20X40
R456 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R500 0662057M81 RES. CHIP 2000 5% 20X40
R600 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R603 – NOT PLACED
R606 0662057N23 RES. CHIP 100K 5% 20X40
SC400 – NOT PLACED
U200 5185963A50 IC CMOS KRSIC
U201 5105457W85 CC ADDAG IC
U202 5113818A14 IC DL OP AMP RAIL TO RAIL
U300 5109841C69 IC 256 BGA 17X17 PACKAGE
PATRIOT
U301 5185368C95 IC BURST FLASH 32MB
U302 5185130C38 IC SRAM 4MG
U303 5105109Z31 IC QUAD 2:1 MUX/DEMUX
U304 5185368C53 IC USB TRANSCEIVER 14 PIN
TSSOP14
U305 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U306 5113837A15 IC 3.3V QUAD BUFFER
U307 5113837A02 IC NOR QUAD 2 IN MC
74LCX02DTR
U400 5185368C55 ICDIGITAL EEPOT 8 PIN S08
U401 5185368C55 ICDIGITAL EEPOT 8 PIN S08
U402 5105109Z38 3 VOLT LINEAR PCM CODEC
FILTER
U404 5113818A14 IC DL OP AMP RAIL TO RAIL
U408 5185623B01 HIGH SPEED CMOS INVERTER
U409 5185353D93 IC AHCMOS SINGER GATE
BUFFERED INVERTER
U410 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
U411 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
U412 5185353D46 IF 4.3V VOLTAGE DETECTOR
U500 5113805C01 IC LN DRVR/RCVR 3V
U501 5113805C01 IC LN DRVR/RCVR 3V
U502 5113805C01 IC LN DRVR/RCVR 3V
U503 5113837A07 IC LINE DRVR OCT3
MC74LCX244DT
U504 5113837A07 IC LINE DRVR OCT3
MC74LCX244DT
U600 5113805B16 IC CNTR DL 4 STAGE BIN
HC393D
U601 5113806A05 IC FLIP-FLOP,DUAL D
U602 5113805B44 IC OR QUAD 2-IN
VR301 4813830A11 DIODE 3.9V 5% 225MW
MMBZ5228B_
VR302 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR303 4813830A15 DIODE 5.6V 5% 225MW
MMBZ5232B_
VR304 4813830A22 DIODE 9.1V 5% 225MW
MMBZ5239B_
VR305 4813830A15 DIODE 5.6V 5% 225MW
MMBZ5232B_
Y400 4885071E01 MODULE REFERENCE
OSCILLATOR 16.8 MHZ 5X3.2
MM
Y401 4809995L05 XTAL QUARTZ 32.768KHZ
CC4V-T1
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
