Motorola ASTRO Digital Spectra User Manual

Schematics, Component Location Diagrams and Parts Lists: VCO Section 7-105
6881076C25-E September 5, 2008
HLE6000D and HLE6041D UHF VCO Parts List
Notes:
1. Valid in HLE6000D only.
2. Valid in HLE6041D only.
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
C5630 &
C5631
2113741N45 CAP CHIP CL2 X7R 10%
10000
C5640 2311049J26 CAP TANT CHIP 10 20 16
C5641 2311049A35 CAP TANT CHIP 0.47 20
25
C5642 &
C5643
2113740B76 CAP CHIP REEL CL1 +/-30
1500
C5646 2113740B49 CAP CHIP REEL CL1 +/-30
100
C5650 2311049A37 CAP TANT CHIP 1 20 20
C5651 thru
C5658
2113740B49 CAP CHIP REEL CL1 +/-30
100
C5661 2113741N45 CAP CHIP CL2 X7R 10%
10000
C5662 2113740B28 CAP CHIP REEL CL1 +/-30
13
C5663 thru
C5665
2113741N45 CAP CHIP CL2 X7R 10%
10000
C5666 2311049J26 CAP TANT CHIP 10 20 16
C5670 2113740B34 CAP CHIP REEL CL1 +/-30
24
C5671 2113740B39 CAP CHIP REEL CL1 +/-30
39
C5672 2113740B17 CAP CHIP REEL CL1 +/-30
4.7
C5673 2113740B27 CAP CHIP REEL CL1 +/-30
12
C5674 2113740B29 CAP CHIP REEL CL1 +/-30
15
C5675 2113740B25 CAP CHIP REEL CL1 +/-30
10
C5676 2113741N45 CAP CHIP CL2 X7R 10%
10000
C5677 2113740B09 CAP CHIP REEL CL1 +/-30
2.2
C5680 2113740B27 CAP CHIP REEL CL1 +/-30
12
C5682 thru
C5684
2113741N45 CAP CHIP CL2 X7R 10%
10000
C5685 &
C5686
2113740B19 CAP CHIP REEL CL1 +/-30
5.6
C5687 &
C5688
2113741N45 CAP CHIP CL2 X7R 10%
10000
C5690 thru
C5693
2113741N45 CAP CHIP CL2 X7R 10%
10000
C5695 thru
C5699
2113741N45 CAP CHIP CL2 X7R 10%
10000
CR5640 &
CR5641
4880066M01 DIODE SIGNAL RLS4148
CR5690 &
CR5691
4880154K05 DIODE CMN CATH DUAL
PIN SOT23
J5641 0980110M01 RECP COAX PCBMOUNT
J5642 0980212N03 RECP COAX PCB MOUNT
JU5641 &
JU5642
– NOT PLACED
JU5643 0611077A01
–
RES CHIP JUMPER
1
NOT PLACED
2
JU5644 –
0611077A01
NOT PLACED
1
RES CHIP JUMPER
2
JU5668 0611077A01 RES CHIP JUMPER
JU5669 – NOT PLACED
JU5680 thru
Ju5683
0611077A01 RES CHIP JUMPER
L5660 2480140E04 INDUCTOR CHIP 65 NH
L5670 2480091G21 COIL AIRWOUND
L5671 2480091G24 COIL AIRWOUND
L5672 &
L5673
2480091G21 COIL AIRWOUND
L5674 2480091G06 COIL AIRWOUND
L5680 2480091G20 COIL AIRWOUND
L5681 2480091G24 COIL AIRWOUND
L5682 2480091G32 COIL AIRWOUND
L5683 – NOT PLACED
MP5655 1180117M01 ADHESIVE PREFORM
VCO
MP5676 1580223N02 COVER SHIELD
P0601 2880099M02 PLUG VERTICAL
Q5630 4813827A03 TSTR NPN SML SIG
MMBR901LT1 7X
Q5640 &
Q5650
4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q5651 4880141L02 TSTR NPN SOT23 LO
PROFILE TAPE
Q5652 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q5653 4880141L02 TSTR NPN SOT23 LO
PROFILE TAPE
Q5660 4813827A03 TSTR NPN SML SIG
MMBR901LT1 7X
Q5670 &
Q5680
4880182D50 TSTR SI SORF 4V 750MW
960MHZ
Q5681 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
R5630 0611077A32 RES CHIP 18 5 1/8W
R5631 0611077A46 RES CHIP 68 5 1/8W
R5632 0611077A32 RES CHIP 18 5 1/8W
R5633 0611077A50 RES CHIP 100 5 1/8W
R5634 0611077A50 RES CHIP 100 5 1/8W
R5635 0611077A82 RES CHIP 2200 5 1/8
R5636 0611077A74 RES CHIP 1000 5 1/8
R5639 0611077A01
0611077A94
RES CHIP JUMPER
1
RES CHIP 6800 5 1/8
2
R5640 0611077A98 RES CHIP 10K 5 1/8W
R5641 0611077A90 RES CHIP 4700 5 1/8
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
R5642 0611077A98 RES CHIP 10K 5 1/8W
R5643 0611077B07
0611077A90
RES CHIP 22K 5 1/8W
1
RES CHIP 4700 5 1/8
2
R5645 0611077A32 RES CHIP 18 5 1/8W
R5646 0611077B19 RES CHIP 68K 5 1/8W
R5647 0611077A90 RES CHIP 4700 5 1/8
R5648 0611077B31 RES CHIP 220K 5 1/8W
R5649 0611077B47 RES CHIP 1 MEG 5 1/8W
R5650 0611077A98 RES CHIP 10K 5 1/8W
R5651 0611077B47 RES CHIP 1 MEG 5 1/8W
R5652 0611077A60 RES CHIP 270 5 1/8W
R5653 0611077B23 RES CHIP 100K 5 1/8W
R5654 0611077A60 RES CHIP 270 5 1/8W
R5655 0611077B47 RES CHIP 1 MEG 5 1/8W
R5656 0611077A68 RES CHIP 560 5 1/8W
R5657 0611077B23 RES CHIP 100K 5 1/8W
R5658 0611077A98 RES CHIP 10K 5 1/8W
R5659 0611077B23 RES CHIP 100K 5 1/8W
R5660 0611077B47 RES CHIP 1 MEG 5 1/8W
R5661 &
R5662
0611077A46 RES CHIP 68 5 1/8W
R5664 0611077A82 RES CHIP 2200 5 1/8
R5665 0611077A74 RES CHIP 1000 5 1/8
R5666 &
R5667
0611077A50 RES CHIP 100 5 1/8W
R5670 0611077A90 RES CHIP 4700 5 1/8
R5671 &
R5672
0611077A74 RES CHIP 1000 5 1/8
R5674 0611077A36 RES CHIP 27 5 1/8W
R5675 0611077A74 RES CHIP 1000 5 1/8
R5676 0611077A68 RES CHIP 560 5 1/8W
R5677 0611077A30 RES CHIP 15 5 1/8W
R5678 0611077A68 RES CHIP 560 5 1/8W
R5679 &
R5680
0611077A74 RES CHIP 1000 5 1/8
R5681 0611077A82 RES CHIP 2200 5 1/8
R5682 0611077A74 RES CHIP 1000 5 1/8
R5683 0611077A46 RES CHIP 68 5 1/8W
R5684 0611077A50 RES CHIP 100 5 1/8W
R5686 0611077A46 RES CHIP 68 5 1/8W
R5687 0611077A50 RES CHIP 100 5 1/8W
R5688 0611077A74 RES CHIP 1000 5 1/8
R5689 0611077A68 RES CHIP 560 5 1/8W
R5690 0611077A26 RES CHIP 10 5 1/8W
R5691 0611077A68 RES CHIP 560 5 1/8W
R5692 thru
R5696
0611077A74 RES CHIP 1000 5 1/8
R5697 0611077A58 RES CHIP 220 5 1/8W
R5698 0611077A40 RES CHIP 39 5 1/8W
R5699 0611077A58 RES CHIP 220 5 1/8W
3280247N01 GASKET VCO
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
8480208N37 BD CKT UHF VCO CAR
BFRPNL
8480208N07 BD CKT UHF VCO CAR
BFR
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
