Schematics, Component Location Diagrams and Parts Lists: RX Front-End Section 7-123
6881076C25-E September 5, 2008
HRF6004B/C 800 MHz RXFE Parts List
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C8126 2111078B42 CAP CHIP RF 100 5 NPO 100V
C8129 2111059D57 CAP CHIP 21D84873H57 A/I
C8130 2111059B11 CAP CHIP 21D84547A11 A/I
C8131 2113741N69 CAP CHIP CL2 X7R 10%
100000
C8132
thru
C8136
2111059B11 CAP CHIP 21D84547A11 A/I
E8126 9180087M02 FILTER CER 6 P 938MHZ
E8127 2680002M02 SHLD INJ FLTR TIN PLATED
E8130 2680010N02 SHLD RCVR FNT END TIN
PLATED
J9127 0980110M01 RECP COAX PCBMOUNT
L8129 2480140E06 INDUCTOR CHIP 130 NH
L8130 2480140E10 INDUCTOR CHIP 100NH
L8131 2480140E01 INDUCTOR CHIP 1.2 UH
L8132 2480140E01 INDUCTOR CHIP 1.2 UH
MP8126 0780259M02 FRAME TIN PLATED
MP8127 6480100P01 SBSTR RECEIVER FRONT
END
MP8128 0780031P01 BRKT RCVR FRONT END
Q8126 4802000P02 NEC SILICON TR 2SC3357 RE
Q8127 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q8128 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
R8126 0611077B15 RES CHIP 47K 5 1/8W
R8127 0611077A98 RES CHIP 10K 5 1/8W
R8128 0611077A50 RES CHIP 100 5 1/8W
R8129 0611077A54 RES CHIP 150 5 1/8W
R8130 0611077A38 RES CHIP 33 5 1/8W
R8131 0611077A54 RES CHIP 150 5 1/8W
R8132 0611077A01 RES CHIP JUMPER
R8134 0611077A98 RES CHIP 10K 5 1/8W
R8135 0611077A64 RES CHIP 390 5 1/8W
W8127 3080037R05 CABLE ASSEMBLY
W8128 3080152M07 CBL COAX ASSEMBLY
4285615C01 CLIP, GROUND
8480106P02 BD THK FLM MIXER
To Next Page
