Motorola ASTRO Digital Spectra User Manual

Schematics, Component Location Diagrams and Parts Lists: Power Amplifier Section 7-127
6881076C25-E September 5, 2008
HLD6022C VHF 50-Watt PA Parts List
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C3801 2113741N21 CAP CHIP CL2 X7R 10% 1000
C3802
thru
C3805
2113741N45 CAP CHIP CL2 X7R 10% 10000
C3806 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3807 2113740B41 CAP CHIP REEL CL1 +/-30 47
C3808 2113740B48 CAP CHIP REEL CL1 +/-30 91
C3810 &
C3811
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3812 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3813 &
C3815
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3816 &
C3817
2113740B44 CAP CHIP REEL CL1 +/-30 62
C3818 2113741N69 CAP CHIP CL2 X7R 10%
100000
C3819 2113740B44 CAP CHIP REEL CL1 +/-30 62
C3831 &
C3832
– NOT PLACED
C3834 2113743G24 CAP CHIP 2.2 UF 16V +80-20%
C3835 &
C3836
– NOT PLACED
C3850
thru
C3852
2111078B49 CAP CHIP RF 180 5 NPO 100V
C3855 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3856 2380090M24 CAP ALU 10 20 50V SURF MT
C3857 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3858 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3859 2113741N69 CAP CHIP CL2 X7R 10%
100000
C3875 &
C3876
2111078B49 CAP CHIP RF 180 5 NPO 100V
C3877 2111078B42 CAP CHIP RF 100 5 NPO 100V
C3878 2111078B27 CAP CHIP RF 30 5 NPO 100V
C3879 2111078B59 CAP CHIP RF 470 5 NPO 100V
C3880 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3881 2113741N69 CAP CHIP CL2 X7R 10%
100000
C3882 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3883
thru
C3885
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3890
thru
C3901
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3902 2113740B36 CAP CHIP REEL CL1 +/-30 30
C3903 &
C3904
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3910 2111078B59 CAP CHIP RF 470 5 NPO 100V
C3911 2111078B19 CAP CHIP RF 16 5 NPO 100V
C3912 2111078B19 CAP CHIP RF 16 5 NPO 100V
C3913 2111078B31 CAP CHIP RF 36 5 NPO 100V
C3914 2111078B23 CAP CHIP RF 24 5 NPO 100V
C3920 &
C3921
2111078B22 CAP CHIP RF 22 5 NPO 100V
C3922
thru
C3924
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3925 2111078B19 CAP CHIP RF 16 5 NPO 100V
C3926 &
C3927
2113740B65 CAP CHIP REEL CL1 +/-30 470
CR3875 4880236E07 DIODE TRANSIENT SUP
CR3900 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
CR3920 &
CR3921
4880236E24 DIODE PIN
CR3922 4805119G18 DIODE SMBD1023 STEP
RECOVERY
E3800 2680187N02 HEATSINK, TO39
E3801 2680188N02 SHLD HAR FILTER FENCE TIN
PLAT
E3803 8480176N34 BD CK 50W PA PNL
E3850
thru
E3852
2980014A03 CLIP COAX TERMINAL
L3801 2480067M01 CHK RF CHIP BEAD
INDUCTOR 28MZ
L3802 2480091G23 COIL AIRWOUND
L3806 2484657R01 INDUCTOR BEAD CHIP
L3807 2480091G23 COIL AIRWOUND
L3810 2480067M01 CHK RF CHIP BEAD
INDUCTOR 28MZ
L3811 &
L3851
2480091G24 COIL AIRWOUND
L3852 2484657R01 INDUCTOR BEAD CHIP
L3853 2480091G23 COIL AIRWOUND
L3854 2484657R01 INDUCTOR BEAD CHIP
L3875 2480090G03 COIL AIRWOUND
L3876 2484657R01 INDUCTOR BEAD CHIP
L3877 2480090G03 COIL AIRWOUND
L3890 2484657R01 INDUCTOR BEAD CHIP
L3900 &
L3903
2480140E01 INDUCTOR CHIP 1.2 UH
L3904 2480067M01 CHK RF CHIP BEAD
INDUCTOR 28MZ
L3911 2480090G15 COIL AIRWOUND
L3912 2480090G10 COIL AIRWOUND
L3913 2480090G15 COIL AIRWOUND
L3914 2480090G13 COIL AIRWOUND
L3920 &
L3921
2480090G14 COIL AIRWOUND
L3922 2480140E01 INDUCTOR CHIP 1.2 UH
P0850 2880102M06 PLUG VERTICAL 12 POSITION
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
P0853 0980103M04 RECEPTICAL RIGHT ANGLE
12 POS
Q3801 4880182D50 TSTR SI SORF 4V 750MW
960MHZ
Q3802 4880141L01 TSTR PNP SOT23 LO PROFILE
TAPE
Q3804 4800869859 TSTR NPN 69859
Q3806 4880141L02 TSTR NPN SOT23 LO PROFILE
TAPE
Q3850 4880225C28 TSTR RF MRF2628 IN FLANGE
PKG
Q3875 4884411L04 TSTR M1104
R3801 0611077A26 RES CHIP 10 5 1/8W
R3802 0611077A54 RES CHIP 150 5 1/8W
R3803 0611077A43 RES CHIP 51 5 1/8W
R3804 0611077A26 RES CHIP 10 5 1/8W
R3805 0611077A82 RES CHIP 2200 5 1/8
R3806 0611077A26 RES CHIP 10 5 1/8W
R3807 0611077A86 RES CHIP 3300 5 1/8
R3808 0611077A82 RES CHIP 2200 5 1/8
R3809 0611077A74 RES CHIP 1000 5 1/8
R3810 0611077A43 RES CHIP 51 5 1/8W
R3811 – NOT PLACED
R3812 0611077A74 RES CHIP 1000 5 1/8
R3813 0611077A50 RES CHIP 100 5 1/8W
R3815 0611077A26 RES CHIP 10 5 1/8W
R3816 0611077A80 RES CHIP 1800 5 1/8
R3817 0611077A74 RES CHIP 1000 5 1/8
R3818 0611077A62 RES CHIP 330 5 1/8W
R3850 0611077A26 RES CHIP 10 5 1/8W
R3851 0611077A26 RES CHIP 10 5 1/8W
R3875 1780228N02 RESISTOR SHUNT
R3876 0680195M01 RES CHIP 10 OHMS 5% .5W
R3878 0611077A70 RES CHIP 680 5 1/8W
R3879 – NOT PLACED
R3880 0611077A90 RES CHIP 4700 5 1/8
R3900 &
R3901
0680194M18 RES 51 OHMS 5% 1W
R3903 0680195M25 RES CHIP 100 OHMS 5% .5W
R3904 0611077B11 RES CHIP 33K 5 1/8W
R3905 &
R3906
0611077A74 RES CHIP 1000 5 1/8
R3907 0611077A78 RES CHIP 1500 5 1/8
R3910
thru
R3912
0611077A50 RES CHIP 100 5 1/8W
R3920 &
R3921
0611077A72 RES CHIP 820 5 1/8W
RT3877 &
RT3905
0680149M02 THERMISTOR CHIP 100K OHM
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
