Motorola ASTRO Digital Spectra User Manual

Schematics, Component Location Diagrams and Parts Lists: Power Amplifier Section 7-131
6881076C25-E September 5, 2008
HLD6064C VHF R1 and HLD6063D R2 100-Watt PA
Parts List
Notes;
1. Valid in HLD6064C only.
2. Valid in HLD6063D only.
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C3801 &
C3802
2113741N45 CAP CHIP CL2 X7R 10% 10000
C3804 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3807 2113740B36 CAP CHIP REEL CL1 +/-30 30
C3808 2113740B48 CAP CHIP REEL CL1 +/-30 91
C3809 2113741N69 CAP CHIP CL2 X7R 10% 100000
C3810 2113740B76 CAP CHIP REEL CL1 +/-30 1500
C3812 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3816 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3818 2113740B39
1
2113740B36
2
CAP CHIP REEL CL1 +/-30 39
CAP CHIP REEL CL1 +/-30 30
C3819 2113740B35
1
2113740B36
2
CAP CHIP REEL CL1 +/-30 27
CAP CHIP REEL CL1 +/-30 30
C3820 2111078B49
1
2111078B47
2
CAP CHIP RF 180 5 NPO 100V
CAP CHIP RF 150 5 NPO 100V
C3821 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3824 2113740B65
1
2113740B57
2
CAP CHIP REEL CL1 +/-30 470
CAP CHIP REEL CL1 +/-30 220
C3835 2113741N69 CAP CHIP CL2 X7R 10% 100000
C3836 2113741N45
1
2113741N69
2
CAP CHIP CL2 X7R 10% 10000
CAP CHIP CL2 X7R 10% 100000
C3840
thru
C3844
2113741N45 CAP CHIP CL2 X7R 10% 10000
C3846
thru
C3849
2113741N45 CAP CHIP CL2 X7R 10% 10000
C3851 2111078B44 CAP CHIP RF 120 5 NPO 100V
C3852 2111078B40 CAP CHIP RF 82 5 NPO 100V
C3853 2111078B44
1
2111078B42
2
CAP CHIP RF 120 5 NPO 100V
CAP CHIP RF 100 5 NPO 100V
C3856 2111078B59
1
2111078B51
2
CAP CHIP RF 470 5 NPO 100V
CAP CHIP RF 220 5 NPO 100V
C3857 2111078B47
1
2111078B44
2
CAP CHIP RF 150 5 NPO 100V
CAP CHIP RF 120 5 NPO 100V
C3858
thru
C3859
2111078B49
1
2111078B47
2
CAP CHIP RF 180 5 NPO 100V
CAP CHIP RF 150 5 NPO 100V
C3860 2111078B49 CAP CHIP RF 180 5 NPO 100V
C3861 &
C3862
2111078B51
1
2111078B49
2
CAP CHIP RF 220 5 NPO 100V
CAP CHIP RF 180 5 NPO 100V
C3863 2111078B49 CAP CHIP RF 180 5 NPO 100V
C3870 &
C3871
2113741N69 CAP CHIP CL2 X7R 10% 100000
C3872
thru
C3875
2111078B49 CAP CHIP RF 180 5 NPO 100V
C3878 2111078B40
1
2111078B37
2
CAP CHIP RF 82 5 NPO 100V
CAP CHIP RF 62 5 NPO 100V
C3880 2113741N69 CAP CHIP CL2 X7R 10% 100000
C3881 2111078B59 CAP CHIP RF 470 5 NPO 100V
C3882 2111078B40
1
2111078B37
2
CAP CHIP RF 82 5 NPO 100V
CAP CHIP RF 62 5 NPO 100V
C3886 2111078B40 CAP CHIP RF 82 5 NPO 100V
C3887 2111078B40
1
2111078B37
2
CAP CHIP RF 82 5 NPO 100V
CAP CHIP RF 62 5 NPO 100V
C3888 2111078B27
1
2111078B25
2
CAP CHIP RF 30 5 NPO 100V
CAP CHIP RF 27 5 NPO 100V
C3889 2111078B59 CAP CHIP RF 470 5 NPO 100V
C3900 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3901 2113740B30 CAP CHIP REEL CL1 +/-30 16
C3902 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3903 2113740B09 CAP CHIP REEL CL1 +/-30 2.2
C3904 &
C3905
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3907 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3908 2111078B59 CAP CHIP RF 470 5 NPO 100V
C3913 2111078B19
1
2111078B15
2
CAP CHIP RF 16 5 NPO 100V
CAP CHIP RF 12 5 NPO 100V
C3914 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3917 2113740B36 CAP CHIP REEL CL1 +/-30 30
C3919 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3920 2113740B36 CAP CHIP REEL CL1 +/-30 30
C3931 &
C3932
2380090M32 CAP ALU 220 20 35V
C3933 2111078B44
1
2111078B42
2
CAP CHIP RF 120 5 NPO 100V
CAP CHIP RF 100 5 NPO 100V
C3935 2113741N69 CAP CHIP CL2 X7R 10% 100000
C3936 2111078B59 CAP CHIP RF 470 5 NPO 100V
C3937 2380090M24 CAP ALU 10 20 50V SURF MT
CR3840 4880222R01 DIODE REVERSE POLARITY
SPECTRA
CR3901
&
CR3902
4880121R01 PWR PIN DIODE SMD TAPE &
REEL
CR3903 4880142L01 DIODE PIN SOT 23 MMBV 3401
CR3904 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
J0001 2880102M11 PLUG VERTICAL 12 POS
J3850 4280088P01 CLIP COAX
J3851 2980119R01 TERMINAL POWER
J3852 &
J3853
4280088P01 CLIP COAX
L3802 2480091G23 COIL AIRWOUND
L3806 2484657R01 INDUCTOR BEAD CHIP
L3807 2480091G23 COIL AIRWOUND
L3808 2480091G24 COIL AIRWOUND
L3809 2480091G23 COIL AIRWOUND
L3810 2480090G16 COIL AIRWOUND RF 000.000
L3811 &
L3812
2484657R01 INDUCTOR BEAD CHIP
L3840 2484657R01 INDUCTOR BEAD CHIP
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
L3860 2480090G19
1
COIL AIRWOUND
L3870 &
L3871
2480091G23 COIL AIRWOUND
L3880 2480090G19
2
COIL AIRWOUND
L3881 2484657R01 INDUCTOR BEAD CHIP
L3900 2480140E01 INDUCTOR CHIP 1.2 UH
L3901 2480090G16 COIL AIRWOUND RF 000.000
L3902 2480090G20 COIL AIRWOUND
L3903 2480140E01 INDUCTOR CHIP 1.2 UH
L3909 2480091G21 COIL AIRWOUND
L3910 2480140E11 INDUCTOR CHIP 360 NH
L3911 2480090G16 COIL AIRWOUND RF 000.000
L3920 2480090G13
1
COIL AIRWOUND
L3930 2480091G23 COIL AIRWOUND
L3931 2484657R01 INDUCTOR BEAD CHIP
L3933 2480091G23 COIL AIRWOUND
L3934 2484657R01 INDUCTOR BEAD CHIP
L3950 &
L3951
2480090G10 COIL AIRWOUND
MP0001 1580208R01
2
COVER HARMONIC SHIELD
MP0003 3080114R01
2
CBL ASSEM PWR CONN
MP0006 4280261R01
2
CLIP COAX
MP3801 4280202R02 CLIP COAX TIN PLATED
MP3802 2680139P02 SHLD HAR FLTR TIN PLATED
Q3801 4880182D50 TSTR SI SORF 4V 750MW
960MHZ
Q3802 4880141L01 TSTR PNP SOT23 LO PROFILE
TAPE
Q3804 4800869859 TSTR NPN 69859
Q3805 4880225C22 TSTR NPN 174MHZ 3/30W
MRF1946
Q3806 4880141L02 TSTR NPN SOT23 LO PROFILE
TAPE
Q3870 &
Q3871
4884411L04 TSTR M1104
R3802 0611077A46
1
0611077A50
2
RES CHIP 68 5 1/8W
RES CHIP 100 5 1/8W
R3803 0611077A46 RES CHIP 68 5 1/8W
R3804 0611077A26 RES CHIP 10 5 1/8W
R3805 0611077A82 RES CHIP 2200 5 1/8
R3806 0611077A74 RES CHIP 1000 5 1/8
R3807 0611077A86
1
0611077A82
2
RES CHIP 3300 5 1/8
RES CHIP 2200 5 1/8
R3808 0611077A80 RES CHIP 1800 5 1/8
R3809 0611077A74
1
0611077A70
2
RES CHIP 1000 5 1/8
RES CHIP 680 5 1/8W
R3810 0611077A43 RES CHIP 51 5 1/8W
R3811 0611077A74 RES CHIP 1000 5 1/8
R3816 0611077A80 RES CHIP 1800 5 1/8
R3817 0611077A74 RES CHIP 1000 5 1/8
R3818 0611077A62 RES CHIP 330 5 1/8W
R3819 0680195M01 RES CHIP 10 OHMS 5% .5W
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R3822 0611077A26 RES CHIP 10 5 1/8W
R3840 0611077A50 RES CHIP 100 5 1/8W
R3841 0611077A80 RES CHIP 1800 5 1/8
R3843 0611077A50 RES CHIP 100 5 1/8W
R3844 0611077B15
2
RES CHIP 47K 5 1/8W
R3849 1780165C02 RES SHUNT
R3859 0680194M01 RES 10 OHMS 5% 1W
R3870 &
R3871
0680194M18 RES 51 OHMS 5% 1W
R3872 &
R3873
0680194M13 RES 33 OHMS 5% 1W
R3879 0680195M01 RES CHIP 10 OHMS 5% .5W
R3900 &
R3901
0680194M18 RES 51 OHMS 5% 1W
R3902 &
R3903
0611077A54 RES CHIP 150 5 1/8W
R3904 0611077A52 RES CHIP 120 5 1/8W
R3906 0611077A78 RES CHIP 1500 5 1/8
R3908 0611077B11 RES CHIP 33K 5 1/8W
R3909 0611077B15 RES CHIP 47K 5 1/8W
R3910 0611077A66 RES CHIP 470 5 1/8W
R3913 &
R3914
0611077B47 RES CHIP 1 MEG 5 1/8W
R3916 0611077B07 RES CHIP 22K 5 1/8W
R3920 0680195M01 RES CHIP 10 OHMS 5% .5W
R4402 &
R4003
0611077A01
2
RES CHIP JUMPER
R4005 &
R4006
0611077A32
1
0611077A26
2
RES CHIP 18 5 1/8W
RES CHIP 10 5 1/8W
R4007 0680194M01 RES 10 OHMS 5% 1W
R4008 0680194M18 RES 51 OHMS 5% 1W
R5001 0611077A26 RES CHIP 10 5 1/8W
R6001 0611077A01
1
RES CHIP JUMPER
R6002 0611077A01
2
RES CHIP JUMPER
RT3842
&
RT3907
0680149M02 THERMISTOR CHIP 100K OHM
8480112P05 BD CKT VHF
3080152M13 CBL COAX ASSEM
3080261M06 CBL ANTENNA CONN
0180756T06 HYBRID BD HAR FLTR VHF
SPECTRA
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
