Motorola ASTRO Digital Spectra User Manual

Schematics, Component Location Diagrams and Parts Lists: Power Amplifier Section 7-135
6881076C25-E September 5, 2008
HLD6032B VHF R2 25-Watt PA Parts List HLD6066B VHF R1 25-Watt PA Parts List
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C3800 2113740B39 CAP CHIP REEL CL1 +/-30 39
C3801 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3802 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3803 2113741N69 CAP CHIP CL2 X7R 10% 100000
C3804 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3805 &
C3806
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3807 2113740B39 CAP CHIP REEL CL1 +/-30 39
C3809 2113740B49 CAP CHIP REEL CL1 +/-30 100
C3810 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3811 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3812 2113741N69 CAP CHIP CL2 X7R 10% 100000
C3813 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3815 2113740B49 CAP CHIP REEL CL1 +/-30 100
C3816 2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C3817 2113740B34 CAP CHIP REEL CL1 +/-30 24
C3819 2113740B44 CAP CHIP REEL CL1 +/-30 62
C3820 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3821 2113740B41 CAP CHIP REEL CL1 +/-30 47
C3822 2113740B49 CAP CHIP REEL CL1 +/-30 100
C3823 2113740B44 CAP CHIP REEL CL1 +/-30 62
C3856 2380090M24 CAP ALU 10 20 50V SURF MT
C3874 2113741N69 CAP CHIP CL2 X7R 10% 100000
C3875 2111078B49 CAP CHIP RF 180 5 NPO 100V
C3877 2111078B42 CAP CHIP RF 100 5 NPO 100V
C3879 2111078B59 CAP CHIP RF 470 5 NPO 100V
C3880 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3881 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3882 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3883
thru
C3885
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3889 &
C3890
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3891 2113741N69 CAP CHIP CL2 X7R 10% 100000
C3892
thru
C3895
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3900 &
C3901
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3902 2113740B23 CAP CHIP REEL CL1 +/-30 8.2
C3903 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3904 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3910 2111078B59 CAP CHIP RF 470 5 NPO 100V
C3911 2111078B19 CAP CHIP RF 16 5 NPO 100V
C3912 2111078B31 CAP CHIP RF 36 5 NPO 100V
C3913 2111078B27 CAP CHIP RF 30 5 NPO 100V
C3914 &
C3920
2111078B22 CAP CHIP RF 22 5 NPO 100V
C3921 &
C3922
2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C3923 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3925 2113740B17 CAP CHIP REEL CL1 +/-30 4.7
C3926
thru
C3928
2113740B65 CAP CHIP REEL CL1 +/-30 470
CR3875 4880236E07 DIODE TRANSIENT SUP
CR3900 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
CR3922 4805119G18 DIODE SMBD1023 STEP
RECOVERY
E3800 2680187N02 HEATSINK, TO39
E3803 8480259N33 CKT BD VHF 25W PANEL
E3804 8480259N03 CKT BD VHF 25W PA
E3850 2980014A03 CLIP COAX TERMINAL
E3851 3080152M10 CBL COAX ASSEMBLY
E3852 2980014A03 CLIP COAX TERMINAL
E3854 3080152M02 CABLE COAX ASSEMBLY
L3800 2480091G24 COIL AIRWOUND
L3801 2480067M01 CHK RF CHIP BEAD INDUCTOR
28MZ
L3802 2480091G23 COIL AIRWOUND
L3807 2480091G07 COIL AIRWOUND
L3808 2480067M01 CHK RF CHIP BEAD INDUCTOR
28MZ
L3811 2480091G24 COIL AIRWOUND
L3851 2480091G23 COIL AIRWOUND
L3852 2480067M01 CHK RF CHIP BEAD INDUCTOR
28MZ
L3875 2480090G16 COIL AIRWOUND RF 000.000
L3877 2480090G03 COIL AIRWOUND
L3900 &
L3903
2480140E01 INDUCTOR CHIP 1.2 UH
L3904 2480067M01 CHK RF CHIP BEAD INDUCTOR
28MZ
L3911 2480090G15 COIL AIRWOUND
L3912 2480090G10 COIL AIRWOUND
L3913 2480090G15 COIL AIRWOUND
L3914 2480090G13 COIL AIRWOUND
L3920 2480090G14 COIL AIRWOUND
L3921 2480090G03 COIL AIRWOUND
L3922 2480140E01 INDUCTOR CHIP 1.2 UH
P0853 6480262N01 PLATE LP FEEDTHRU
ASSEMBLY
Q3801 4880182D50 TSTR SI SORF 4V 750MW
960MHZ
Q3802 4880141L01 TSTR PNP SOT23 LO PROFILE
TAPE
Q3804 4800869859 TSTR NPN 69859
Q3806 4880141L02 TSTR NPN SOT23 LO PROFILE
TAPE
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
Q3850 4880225C22 TSTR NPN 174MHZ 3/30W
MRF1946
R3800 0611077A01 RES CHIP JUMPER
R3801 0611077A26 RES CHIP 10 5 1/8W
R3802 0611077A54 RES CHIP 150 5 1/8W
R3803 0611077A36 RES CHIP 27 5 1/8W
R3804 0611077A26 RES CHIP 10 5 1/8W
R3805 0611077A82 RES CHIP 2200 5 1/8
R3806 0611077A54 RES CHIP 150 5 1/8W
R3807 0611077A10 RES CHIP 2.2 5 1/8W
R3809 0611077A74 RES CHIP 1000 5 1/8
R3810 0611077A43 RES CHIP 51 5 1/8W
R3811 0611077A50 RES CHIP 100 5 1/8W
R3812 0611077A74 RES CHIP 1000 5 1/8
R3813 0611077A86 RES CHIP 3300 5 1/8
R3814 0611077A82 RES CHIP 2200 5 1/8
R3815 0611077A26 RES CHIP 10 5 1/8W
R3816 0611077A80 RES CHIP 1800 5 1/8
R3817 0611077A74 RES CHIP 1000 5 1/8
R3818 0611077A62 RES CHIP 330 5 1/8W
R3819 0611077A32 RES CHIP 18 5 1/8W
R3820 0611077A50 RES CHIP 100 5 1/8W
R3821 0611077A58 RES CHIP 220 5 1/8W
R3875 1780228N01 RESISTOR SHUNT
R3876 &
R3877
0611077A26 RES CHIP 10 5 1/8W
R3878 0611077A94 RES CHIP 6800 5 1/8
R3879 0611077B23 RES CHIP 100K 5 1/8W
R3881 0611077A50 RES CHIP 100 5 1/8W
R3900 &
R3901
0680194M18 RES 51 OHMS 5% 1W
R3903 0680195M25 RES CHIP 100 OHMS 5% .5W
R3904 0611077B11 RES CHIP 33K 5 1/8W
R3905 0611077A74 RES CHIP 1000 5 1/8
R3906 &
R3907
0611077A78 RES CHIP 1500 5 1/8
R3908 0611077A50 RES CHIP 100 5 1/8W
R3920 &
R3921
0611077A72 RES CHIP 820 5 1/8W
RM0002 0611077A01 RES CHIP JUMPER
RT3876 &
RT3905
0680149M02 THERMISTOR CHIP 100K OHM
2484657R01 INDUCTOR BEAD CHIP
4880236E24 DIODE PIN
2111078B32 CAP CHIP RF 39 5 NPO 100V
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C3801 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3802 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3803 2113741N69 CAP CHIP CL2 X7R 10% 100000
C3804 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3805 &
C3806
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3807 2113740B39 CAP CHIP REEL CL1 +/-30 39
C3809 2113740B49 CAP CHIP REEL CL1 +/-30 100
C3810 2113741N45 CAP CHIP CL2 X7R 10% 10000
C3811 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3812 2113741N69 CAP CHIP CL2 X7R 10% 100000
C3813 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3815 2113740B49 CAP CHIP REEL CL1 +/-30 100
C3816 2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C3817 2113740B34 CAP CHIP REEL CL1 +/-30 24
C3819 2113740B47 CAP CHIP REEL CL1 +/-30 82
C3820 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3821 &
C3822
2113740B44 CAP CHIP REEL CL1 +/-30 62
C3823 2113740B47 CAP CHIP REEL CL1 +/-30 82
C3856 2380090M24 CAP ALU 10 20 50V SURF MT
C3874 2113741N69 CAP CHIP CL2 X7R 10% 100000
C3875 2111078B49 CAP CHIP RF 180 5 NPO 100V
C3877 2111078B42 CAP CHIP RF 100 5 NPO 100V
C3878 2111078B32 CAP CHIP RF 39 5 NPO 100V
C3879 2111078B59 CAP CHIP RF 470 5 NPO 100V
C3880 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3881 &
C3882
2113741N45 CAP CHIP CL2 X7R 10% 10000
C3883
thru
C3885 &
C3889,
C3890
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3891 2113741N69 CAP CHIP CL2 X7R 10% 100000
C3892
thru
C3895
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3900 &
C3901
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3902 2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C3903 &
C3904
2113740B65 CAP CHIP REEL CL1 +/-30 470
C3910 2111078B59 CAP CHIP RF 470 5 NPO 100V
C3911 2111078B19 CAP CHIP RF 16 5 NPO 100V
C3912 2111078B31 CAP CHIP RF 36 5 NPO 100V
C3913 2111078B27 CAP CHIP RF 30 5 NPO 100V
C3914 &
C3920
2111078B22 CAP CHIP RF 22 5 NPO 100V
C3921 &
C3922
2113740B21 CAP CHIP REEL CL1 +/-30 6.8
