7-144 Schematics, Component Location Diagrams and Parts Lists: Power Amplifier Section
September 5, 2008 6881076C25-E
HLE6043C/D UHF R3 40-Watt Parts List
HLE6044C/D UHF R4 40-Watt PA Parts List
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C5801 &
C5804
2113741N45 CAP CHIP CL2 X7R 10% 10000
C5805 2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C5806 2113740B31 CAP CHIP REEL CL1 +/-30 18
C5807 &
C5808
2113740B49 CAP CHIP REEL CL1 +/-30 100
C5810 2113741N69 CAP CHIP CL2 X7R 10% 100000
C5811 2113740B49 CAP CHIP REEL CL1 +/-30 100
C5813 2113741N45 CAP CHIP CL2 X7R 10% 10000
C5815 2113740B49 CAP CHIP REEL CL1 +/-30 100
C5816 2113743G24 CAP CHIP 2.2 UF 16V +80-20%
C5820 &
C5821
2113740B25 CAP CHIP REEL CL1 +/-30 10
C5822 2113740B05 CAP CHIP REEL CL1 +/-30 1.5
C5823 2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C5824 2113740B27 CAP CHIP REEL CL1 +/-30 12
C5826 2113741N45 CAP CHIP CL2 X7R 10% 10000
C5850 2113740B01 CAP CHIP REEL CL1 +/-30 1.0
C5851 &
C5852
2113740B34 CAP CHIP REEL CL1 +/-30 24
C5853 – NOT PLACED
C5854 2111078B42 CAP CHIP RF 100 5 NPO 100V
C5855 2111078B23 CAP CHIP RF 24 5 NPO 100V
C5856 2113740B49 CAP CHIP REEL CL1 +/-30 100
C5857 2113741N45 CAP CHIP CL2 X7R 10% 10000
C5858 2113740B17 CAP CHIP REEL CL1 +/-30 4.7
C5860
thru
C5862
2113740B49 CAP CHIP REEL CL1 +/-30 100
C5863 2113743G24 CAP CHIP 2.2 UF 16V +80-20%
C5864
thru
C5869
2113740B49 CAP CHIP REEL CL1 +/-30 100
C5875 &
C5876
2111078B32 CAP CHIP RF 39 5 NPO 100V
C5877 &
C5878
2184366F08 CAP MICA 40 5 250V
C5879 – NOT PLACED
C5880 2111078B15 CAP CHIP RF 12 5 NPO 100V
C5881 2113740B49 CAP CHIP REEL CL1 +/-30 100
C5883 2113741N45 CAP CHIP CL2 X7R 10% 10000
C5884 2113741N69 CAP CHIP CL2 X7R 10% 100000
C5885 2380090M24 CAP ALU 10 20 50V SURF MT
C5886 2113741N21 CAP CHIP CL2 X7R 10% 1000
C5887 2111078B19 CAP CHIP RF 16 5 NPO 100V
C5888
thru
C5890
2113740B49 CAP CHIP REEL CL1 +/-30 100
C5891 2113740B17 CAP CHIP REEL CL1 +/-30 4.7
C5892 2111078B13 CAP CHIP RF 10 .5 NPO 100V
C5893 2113741N45 CAP CHIP CL2 X7R 10% 10000
C5894 – NOT PLACED
C5895 2113741N21 CAP CHIP CL2 X7R 10% 1000
C5900 – NOT PLACED
C5901 &
C5902
2113740B49 CAP CHIP REEL CL1 +/-30 100
C5903 2113740B17 CAP CHIP REEL CL1 +/-30 4.7
C5904 2113740B27 CAP CHIP REEL CL1 +/-30 12
C5905 2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C5906 2113740B49 CAP CHIP REEL CL1 +/-30 100
C5907 – NOT PLACED
C5920 2113743G24 CAP CHIP 2.2 UF 16V +80-20%
C5922 2111078B42 CAP CHIP RF 100 5 NPO 100V
C5923 2111078B05 CAP CHIP RF 4.7 .25 NPO 100V
C5924 2111078B08 CAP CHIP RF 6.2 .25 NPO 100V
C5926 &
C5927
2111078B42 CAP CHIP RF 100 5 NPO 100V
C5928 2113740B34 CAP CHIP REEL CL1 +/-30 24
C5930 &
C5931
2113740B49 CAP CHIP REEL CL1 +/-30 100
CR5875 4880236E07 DIODE TRANSIENT SUP
CR5900 4880236E05 DIODE HOT CAR SOT 23
CR5920
&
CR5921
4880236E24 DIODE PIN
CR5922 4805119G18 DIODE SMBD1023 STEP
RECOVERY
J0853 2880102M06 PLUG VERTICAL 12 POSITION
L5801 2480067M01 CHK RF CHIP BEAD INDUCTOR
28MZ
L5802 2480091G21 COIL AIRWOUND
L5805 2480091G23 COIL AIRWOUND
L5806 2480067M01 CHK RF CHIP BEAD INDUCTOR
28MZ
L5809 2480067M01 CHK RF CHIP BEAD INDUCTOR
28MZ
L5810 2484657R01 INDUCTOR BEAD CHIP
L5820 &
L5821
2480091G21 COIL AIRWOUND
L5850 2480091G21 COIL AIRWOUND
L5851 2480091G23 COIL AIRWOUND
L5852 2484657R01 INDUCTOR BEAD CHIP
L5853 2480091G21 COIL AIRWOUND
L5854 2484657R01 INDUCTOR BEAD CHIP
L5875 2480091G21 COIL AIRWOUND
L5876 2480091G36 COIL AIRWOUND
L5878 2480090G03 COIL AIRWOUND
L5879 2480090G05 COIL AIRWOUND
L5883 2484657R01 INDUCTOR BEAD CHIP
L5900 2480091G06 COIL AIRWOUND
L5901 – NOT PLACED
L5902 &
L5903
2480091G24 COIL AIRWOUND
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
L5904 &
L5920
2480091G36 COIL AIRWOUND
L5921 &
L5922
2480090G03 COIL AIRWOUND
L5923 2480091G36 COIL AIRWOUND
P0853 0980103M04 RECEPTICAL RIGHT ANGLE 12
POS
Q5800 4880141L01 TSTR PNP SOT23 LO PROFILE
TAPE
Q5801 4880182D50 TSTR SI SORF 4V 750MW
960MHZ
Q5803 4880225C09 TSTR M25C09
Q5803 2680187N02 HEATSINK, TO39
Q5806 4880141L02 TSTR NPN SOT23 LO PROFILE
TAPE
Q5850 4880225C27 TSTR RF MRF654F IN CS12 PKG
Q5875 4880225C30 TSTR RF 14W/50W UHF .5 CQ
R5801 0611077A26 RES CHIP 10 5 1/8W
R5802 0611077A50 RES CHIP 100 5 1/8W
R5803 0611077A82 RES CHIP 2200 5 1/8
R5805 0611077A26 RES CHIP 10 5 1/8W
R5806 0611077A50 RES CHIP 100 5 1/8W
R5807 0611077A82 RES CHIP 2200 5 1/8
R5808 0611077A90 RES CHIP 4700 5 1/8
R5809 0611077A78 RES CHIP 1500 5 1/8
R5810 0611077A26 RES CHIP 10 5 1/8W
R5811 0611077A74 RES CHIP 1000 5 1/8
R5812 0611077A01 RES CHIP JUMPER
R5813 – NOT PLACED
R5816 0611077A80 RES CHIP 1800 5 1/8
R5817 0611077A74 RES CHIP 1000 5 1/8
R5818 0611077A62 RES CHIP 330 5 1/8W
R5850 0611077A10 RES CHIP 2.2 5 1/8W
R5872 0611077A50 RES CHIP 100 5 1/8W
R5873 0611077A50 RES CHIP 100 5 1/8W
R5875 1780228N01 RESISTOR SHUNT
R5876 0611077B11 RES CHIP 33K 5 1/8W
R5877 0611077A94 RES CHIP 6800 5 1/8
R5878 0611077A86 RES CHIP 3300 5 1/8
R5879 &
R5880
0611077A10 RES CHIP 2.2 5 1/8W
R5881 &
R5882
0611077A19 RES CHIP 5.1 5 1/8W
R5883 &
R5884
0611077A10 RES CHIP 2.2 5 1/8W
R5900 &
R5901
0680194M18 RES 51 OHMS 5% 1W
R5902 &
R5903
– NOT PLACED
R5904 0611077A80 RES CHIP 1800 5 1/8
R5905 0611077B11 RES CHIP 33K 5 1/8W
R5906 0611077A50 RES CHIP 100 5 1/8W
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R5920 &
R5921
0680194M18 RES 51 OHMS 5% 1W
R5922 &
R5923
0611077A78 RES CHIP 1500 5 1/8
R5931
thru
R5933
0611077A01 RES CHIP JUMPER
R5934 – NOT PLACED
RT5875
&
RT5904
0680149M02 THERMISTOR CHIP 100K OHM
8480198N34 BD CKT 40W UHF PA PNL
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C5801 &
C5804
2113741N45 CAP CHIP CL2 X7R 10% 10000
C5805 2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C5806 2113740B31 CAP CHIP REEL CL1 +/-30 18
C5807 &
C5808
2113740B49 CAP CHIP REEL CL1 +/-30 100
C5810 2113741N69 CAP CHIP CL2 X7R 10% 100000
C5811 2113740B49 CAP CHIP REEL CL1 +/-30 100
C5813 2113741N45 CAP CHIP CL2 X7R 10% 10000
C5815 &
C5816
2113740B49 CAP CHIP REEL CL1 +/-30 100
C5820 &
C5821
2113740B24 CAP CHIP REEL CL1 +/-30 9.1
C5822 2113740B05 CAP CHIP REEL CL1 +/-30 1.5
C5823 2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C5824 2113740B27 CAP CHIP REEL CL1 +/-30 12
C5826 2113741N45 CAP CHIP CL2 X7R 10% 10000
C5850 – NOT PLACED
C5851 &
C5852
2113740B34 CAP CHIP REEL CL1 +/-30 24
C5853 2111078B19 CAP CHIP RF 16 5 NPO 100V
C5854 2111078B42 CAP CHIP RF 100 5 NPO 100V
C5855 2111078B22 CAP CHIP RF 22 5 NPO 100V
C5856 2113740B49 CAP CHIP REEL CL1 +/-30 100
C5857 2113741N45 CAP CHIP CL2 X7R 10% 10000
C5858 2113740B17 CAP CHIP REEL CL1 +/-30 4.7
C5860
thru
C5869
2113740B49 CAP CHIP REEL CL1 +/-30 100
C5875 &
C5876
2111078B32 CAP CHIP RF 39 5 NPO 100V
C5877 &
C5878
2184366F08 CAP MICA 40 5 250V
C5879 – NOT PLACED
