Motorola ASTRO Digital Spectra User Manual

Schematics, Component Location Diagrams and Parts Lists: Power Amplifier Section 7-161
6881076C25-E September 5, 2008
HLF6077D 800MHz 35-Watt PA Parts List
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C9500 2311049A37 CAP TANT CHIP 1 20 20
C9560 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9800 &
C9801
2113740B13 CAP CHIP REEL CL1 +/-30 3.3
C9802 2113740B15 CAP CHIP REEL CL1 +/-30 3.9
C9803 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9804 2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C9806
thru
C9808
2113740B39 CAP CHIP REEL CL1 +/-30 39
C9809 – NOT PLACED
C9851 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9852 2113741N69 CAP CHIP CL2 X7R 10% 100000
C9853 2311049A37 CAP TANT CHIP 1 20 20
C9854 2113741N69 CAP CHIP CL2 X7R 10% 100000
C9855 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9856 2111078B42 CAP CHIP RF 100 5 NPO 100V
C9857 2380090M24 CAP ALU 10 20 50V SURF MT
C9858 2111078B29 CAP CHIP RF 33 5 NPO 100V
C9859 – NOT PLACED
C9879 2180240G69 CAP MTL CLAD MICA PF
C9880 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9881 2113741N69 CAP CHIP CL2 X7R 10% 100000
C9882 2113741N45 CAP CHIP CL2 X7R 10% 10000
C9883 2111078B32 CAP CHIP RF 39 5 NPO 100V
C9884 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9885 &
C9890
– NOT PLACED
C9900 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9901 2113740B13 CAP CHIP REEL CL1 +/-30 3.3
C9902 2113740B25 CAP CHIP REEL CL1 +/-30 10
C9903 &
C9920
2113740B39 CAP CHIP REEL CL1 +/-30 39
C9921 2111078B32 CAP CHIP RF 39 5 NPO 100V
C9922 2113740B01 CAP CHIP REEL CL1 +/-30 1.0
C9923 2113740B05 CAP CHIP REEL CL1 +/-30 1.5
C9924
thru
C9929
2113740B39 CAP CHIP REEL CL1 +/-30 39
C9930 2113740B25 CAP CHIP REEL CL1 +/-30 10
C9931 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9932 2311049A37 CAP TANT CHIP 1 20 20
C9933
thru
C9941
2113740B39 CAP CHIP REEL CL1 +/-30 39
C9942 &
C9943
– NOT PLACED
C9945 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9946 – NOT PLACED
C9947 2113740B39 CAP CHIP REEL CL1 +/-30 39
CR9800 4880066M01 DIODE SIGNAL RLS4148
CR9850 4880236E07 DIODE TRANSIENT SUP
CR9900 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
CR9920
thru
CR9922
4880236E24 DIODE PIN
CR9923 4880066M01 DIODE SIGNAL RLS4148
CR9930 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
J9001 2980014A03 CLIP COAX TERMINAL
L9800 2480091G23 COIL AIRWOUND
L9801 2480091G24 COIL AIRWOUND
L9802 2480091G13 COIL AIRWOUND
L9803 2480091G24 COIL AIRWOUND
L9804 2480091G06 COIL AIRWOUND
L9805 2480091G23 COIL AIRWOUND
L9806 2480091G06 COIL AIRWOUND
L9876 2480091G21 COIL AIRWOUND
L9877 2480090G05 COIL AIRWOUND
L9910 &
L9920
2480091G32 COIL AIRWOUND
L9921 2480091G40 COIL AIRWOUND
L9922 2480091G06 COIL AIRWOUND
L9923
thru
L9926
2480091G24 COIL AIRWOUND
L9930 2480091G21 COIL AIRWOUND
MP0001 2680090N02 SHLD MID PWR FENCE TIN
PLATED
P0853 0980103M04 RECEPTICAL RIGHT ANGLE 12
POS
P9227 &
P9741
2980014A03 CLIP COAX TERMINAL
Q9500 4813822D56 TSTR NPN 100V 6A
Q9510 4880048M01 TSTR NPN DIG 47K/47K
Q9515 4880141L01 TSTR PNP SOT23 LO PROFILE
TAPE
Q9800 4880182D50 TSTR SI SORF 4V 750MW
960MHZ
Q9920 4880048M01 TSTR NPN DIG 47K/47K
R9500 0611077A74 RES CHIP 1000 5 1/8
R9501 0611077A28 RES CHIP 12 5 1/8W
R9510 0611077B11 RES CHIP 33K 5 1/8W
R9511 0611077A98 RES CHIP 10K 5 1/8W
R9512 0611077A01 RES CHIP JUMPER
R9513 0611077B07 RES CHIP 22K 5 1/8W
R9560 – NOT PLACED
R9561 0611077A90 RES CHIP 4700 5 1/8
R9562 0611077B11 RES CHIP 33K 5 1/8W
R9563 0611077B21 RES CHIP 82K 5 1/8W
R9800 0611077A54 RES CHIP 150 5 1/8W
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R9801 0611077A74 RES CHIP 1000 5 1/8
R9802 0611077A50 RES CHIP 100 5 1/8W
R9803 – NOT PLACED
R9805 &
R9806
0611077A50 RES CHIP 100 5 1/8W
R9807 &
R9809
– NOT PLACED
R9870 &
R9871
0611077A01 RES CHIP JUMPER
R9872 &
R9873
– NOT PLACED
R9874 0611077A01 RES CHIP JUMPER
R9875 1780228N01 RESISTOR SHUNT
R9876 – NOT PLACED
R9877 &
R9878
0611077A26 RES CHIP 10 5 1/8W
R9901 &
R9902
0680194M18 RES 51 OHMS 5% 1W
R9904 0611077B07 RES CHIP 22K 5 1/8W
R9905 0611077B11 RES CHIP 33K 5 1/8W
R9906 – NOT PLACED
R9920 &
R9921
0680194M18 RES 51 OHMS 5% 1W
R9922
thru
R9927
0611077A74 RES CHIP 1000 5 1/8
R9928 &
R9929
0611077A01 RES CHIP JUMPER
R9930 0611077A52 RES CHIP 120 5 1/8W
R9931 0611077A50 RES CHIP 100 5 1/8W
RT9560 0680149M02 THERMISTOR CHIP 100K OHM
U9850 5180110E01 MODE RF PWR 800MH 20W
2280128P01 PIN POLARIZING
8480156P04 BD CKT PA
