Motorola Commercial CM Series

UHF 1-25W PCB 8486684Z01 (Rev.O) / Schematics 4-21
C347 2113740L09 CAP CER CHIP 4.3 PF +-0.1PF
C348 2113740L08 CAP CER CHIP 3.9 PF+/-0.1PF
C349 2113740F53 CAP CHIP REEL CL1 +/-30 120
C350 2113740F53 CAP CHIP REEL CL1 +/-30 120
C351 2113743E20 CAP CHIP. 10 UF 10%
C353 NOT PLACED GCAM DUMMY PART NUMBER
C354 2113740F49 CAP CHIP REEL CL1 +/-30 82
C355 NOT PLACED GCAM DUMMY PART NUMBER
C356 2113740L22 CAP 15.0 PF 50V 2.0 %
C357 NOT PLACED GCAM DUMMY PART NUMBER
C358 NOT PLACED GCAM DUMMY PART NUMBER
C359 2113740F39 CAP CHIP REEL CL1 +/-30 33
C360 2113740F35 CAP CHIP REEL CL1 +/-30 22
C361 2113740L30 CAP 33.0 PF 50V 2.0 %
C362 2113740F35 CAP CHIP REEL CL1 +/-30 22
C364 NOT PLACED GCAM DUMMY PART NUMBER
C365 NOT PLACED GCAM DUMMY PART NUMBER
C366 2113740L16 CAP CER CHIP 8.2 PF+-0.1PF
C367 2113740L16 CAP CER CHIP 8.2 PF+-0.1PF
C368 2113740F28 CAP CHIP REEL CL1 +/-30 11
C369 2113740F25 CAP CHIP REEL CL1+/-30 8.2
C370 2113740L18 CAP CER CHIP 10.0 PF +/-.25PF
C371 NOT PLACED GCAM DUMMY PART NUMBER
C400 2113740F53 CAP CHIP REEL CL1 +/-30 120
C401 2113743K15 CER CHIP CAP .100UF
C402 NOT PLACED GCAM DUMMY PART NUMBER
C403 2113743K15 CER CHIP CAP .100UF
C404 2113743K15 CER CHIP CAP .100UF
C405 2113743K15 CER CHIP CAP .100UF
C406 2113743K15 CER CHIP CAP .100UF
C407 2113743K15 CER CHIP CAP .100UF
C408 2113743K15 CER CHIP CAP .100UF
Circuit
Ref.
Motorola
Part No.
Description
C410 2113743K15 CER CHIP CAP .100UF
C411 NOT PLACED GCAM DUMMY PART NUMBER
C412 2113740F53 CAP CHIP REEL CL1 +/-30 120
C413 2113740F53 CAP CHIP REEL CL1 +/-30 120
C414 2113740F53 CAP CHIP REEL CL1 +/-30 120
C415 2113740F53 CAP CHIP REEL CL1 +/-30 120
C416 2113740F53 CAP CHIP REEL CL1 +/-30 120
C417 2113740F53 CAP CHIP REEL CL1 +/-30 120
C418 2113740F53 CAP CHIP REEL CL1 +/-30 120
C421 2113743E07 CER CHIP CAP .022UF
C422 2113740F53 CAP CHIP REEL CL1 +/-30 120
C423 2113743K15 CER CHIP CAP .100UF
C490 NOT PLACED GCAM DUMMY PART NUMBER
C5000 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5001 2389289U01 10UF 50V 20% ALUMINUM SMD
C5002 2311049A99 CAP TANT CHIP 47 UF 10V 20%
C5003 2311049A99 CAP TANT CHIP 47 UF 10V 20%
C5005 2360567A03 CAP TANTALUM
C5006 2311049A57 CAP TANT CHIP A/P 10UF 10%
16V
C5007 2311049A99 CAP TANT CHIP 47 UF 10V 20%
C5008 2311049A57 CAP TANT CHIP A/P 10UF 10%
16V
C5009 2311049A57 CAP TANT CHIP A/P 10UF 10%
16V
C5010 2311049A57 CAP TANT CHIP A/P 10UF 10%
16V
C5011 2311049A57 CAP TANT CHIP A/P 10UF 10%
16V
C5012 2311049A56 CAP TAN CHIP A/P 4.7 20 10
C5013 2113928P04 CAP CER CHIP 1.0UF 20% 6.3V
C5014 NOT PLACED GCAM DUMMY PART NUMBER
C5015 2113743K15 CER CHIP CAP .100UF
C5016 2113743K15 CER CHIP CAP .100UF
Circuit
Ref.
Motorola
Part No.
Description
C5017 2113743K15 CER CHIP CAP .100UF
C5018 2113743K15 CER CHIP CAP .100UF
C5019 2113743K15 CER CHIP CAP .100UF
C5020 2113743K15 CER CHIP CAP .100UF
C5021 2113741M69 CAP CHIP CLS2 100000 PF 20V
10
C5022 2113743K15 CER CHIP CAP .100UF
C5023 2113743K15 CER CHIP CAP .100UF
C5024 2113743K15 CER CHIP CAP .100UF
C5025 2113743K15 CER CHIP CAP .100UF
C5026 2113743K15 CER CHIP CAP .100UF
C5027 2113743K15 CER CHIP CAP .100UF
C5028 2113743K15 CER CHIP CAP .100UF
C5029 2113743K15 CER CHIP CAP .100UF
C5030 2113743K15 CER CHIP CAP .100UF
C5031 2113743K15 CER CHIP CAP .100UF
C5032 2113743K15 CER CHIP CAP .100UF
C5033 2113743K15 CER CHIP CAP .100UF
C5034 2113743K15 CER CHIP CAP .100UF
C5035 2113743K15 CER CHIP CAP .100UF
C5036 2113743K15 CER CHIP CAP .100UF
C5037 2113743K15 CER CHIP CAP .100UF
C5038 2113743K15 CER CHIP CAP .100UF
C5039 NOT PLACED GCAM DUMMY PART NUMBER
C5040 NOT PLACED GCAM DUMMY PART NUMBER
C5041 2113743F18 CAP CHIP 2.2 UF 16V +80-20%
C5042 2113743F16 CAP CHIP 1.0UF 16V+80-20%
C5043 2113743F16 CAP CHIP 1.0UF 16V+80-20%
C5044 2113928C04 CAP CER CHIP 4.7UF
6.3V10%0805
C5045 2113743F16 CAP CHIP 1.0UF 16V+80-20%
C5046 2113743E20 CAP CHIP. 10 UF 10%
C5047 2113743E20 CAP CHIP. 10 UF 10%
Circuit
Ref.
Motorola
Part No.
Description
C5048 2113743E20 CAP CHIP. 10 UF 10%
C5049 2113743E20 CAP CHIP. 10 UF 10%
C5050 2113743E20 CAP CHIP. 10 UF 10%
C5051 2113743E20 CAP CHIP. 10 UF 10%
(CM160/CM360)
C5052 2113743E20 CAP CHIP. 10 UF 10%
C5053 2113743E20 CAP CHIP. 10 UF 10%
(CM160/CM360)
C5054 2113743E20 CAP CHIP. 10 UF 10%
(CM160/CM360)
C5055 2113928C04 CAP CER CHIP 4.7UF
6.3V10%0805
C5056 2113928C04 CAP CER CHIP 4.7UF
6.3V10%0805
(CM140/CM160/CM360)
C5057 2113928C04 CAP CER CHIP 4.7UF
6.3V10%0805
C5058 NOT PLACED GCAM DUMMY PART NUMBER
C5059 2113743E07 CER CHIP CAP .022UF
C5060 2113741M69 CAP CHIP CLS2 100000 PF 20V
10
C5061 2113741M69 CAP CHIP CLS2 100000 PF 20V
10
C5062 2113741M69 CAP CHIP CLS2 100000 PF 20V
10
C5063 2113741M69 CAP CHIP CLS2 100000 PF 20V
10
C5064 2113740F53 CAP CHIP REEL CL1 +/-30 120
C5065 2113740F53 CAP CHIP REEL CL1 +/-30 120
C5066 2113740F53 CAP CHIP REEL CL1 +/-30 120
C5067 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5068 2113740F53 CAP CHIP REEL CL1 +/-30 120
C5069 2113740F53 CAP CHIP REEL CL1 +/-30 120
C5070 2113740F53 CAP CHIP REEL CL1 +/-30 120
C5071 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5072 2113740F53 CAP CHIP REEL CL1 +/-30 120
Circuit
Ref.
Motorola
Part No.
Description
