Motorola DS9208 Programming Manual

This document will show you how to program your Motorola DS9208 Omni Directional Barcode
Scanner to read barcodes the way they are formatted in your Corner Store POS database.
Most of your products have UPC-A barcodes that have 12 digits with 10 digits in the middle,
one in the front and one at the end. Here’s an example:
Other products have UPC-E barcodes that have 8 digits with 6 in the middle, one in the front
(usually a zero) and one at the end. Here’s an example:
2
1-866-468-5767 International Point of Sale
201-928-0222 555 Cedar Lane Teaneck,
Our Store Site New Jersey 07666

Motorola DS9208 Specifications

General

Drop Specification	Withstands multiple 5 ft./1.5 m drops to concrete
Scanning Technology	Imager
Tilt Angle	± 65°
Skew Angle	± 60°
Connectivity	USB, RS232, Keyboard Wedge
Decode Capability	1D, 2D and PDF417
Light Source	650nm visible laser diode
Operating Temperature	32° to 104° F/0° to 40° C
Print Contrast	25% minimum reflectance
Pitch Angle	60°
Storage Temperature	-40° to 158° F (-40° to 70° C)
Humidity	5% to 95% relative humidity, non-condensing
Electrical Safety	UL
EMC	FCC Part 15 Class B
Cable Length	6 ft (1.8m)
Power Consumption	2.5 Watts (500mA @ 5V)
Scan Pattern	Omnidirectional
