Motorola GM328

Troubleshooting Flow Chart for 25W Transmitter 3-3
2.0 Troubleshooting Flow Chart for 25W Transmitter (Sheet 1 of 3)
Current
increase
when
keyed?
NO
YES
START
Check if Pressure Pad closes S5440
Check Components between
Q5441 and RF Output,
Antenna Switch
D5471,D5472,Q5472,
VR3471,Q3471
>500mA & <4A
>4A
<500mA
Check PA Stages
Control Volt-
age at
TP5402
>1V
Short TP5403 to
Ground
NO
YES
Voltage at
TP5402
rises?
Check PA Stages
NO
YES
PCIC U5501
Pin 14 9.3V
DC?
Check 9.3 V Regulator
U0641
NO
YES
PCIC U5501
Pin 16 >4V
DC
Replace PCIC U5501
NO
YES
TP5404
9.1V DC
If U5201 Pin 2 is high,
replace PCIC
U5501,otherwise
check controller and
FGU
YES
NO
TP5403
>0.5V DC?
Replace PCIC U5501
Check Forward Power
Sense Circuit (D5451)
Check Forward Power
Sense Circuit (D5451)
NO
YES
PCIC U5501
Pin 5 > 1V
DC?
Check Power Setting,
Tuning & Components
between PCIC Pin 5
and ASFIC (U0221)
Pin 4 before replacing
ASFIC
No or too low Power when keyed
