1-1
Section 1
MODEL CHART AND TECHNICAL SPECIFICATIONS
1.0 GM338 Model Chart
2.0 Technical Specifications
Data is specified for +25°C unless otherwise stated.
GM Series, UHF Band 2, 450-520 MHz
Model Description
AZM25SKF9AA5 GM338 450-520 MHz 25-40W
Item Description
X GCN6114_ GM338 Control Head Direct Mount
X IMUE6019_ Tanapa WM 450-520 MHz 25-40W
X RAE4155_ BNC 470-512 MHz, 1/4 Wave Roof Mount
X RAE4156_ BNC 470-494 MHz, 3.5 Gain Roof Mount
X RAE4157_ BNC 494-512 MHz, 5dB Gain Roof Mount
X 6804112J06 GM338 User Guide
x = Indicates one of each is required.
General Specifications
Channel Capacity
GM338
128
Power Supply 13.2Vdc (10.8 - 15.6Vdc)
Dimensions: H x W x D (mm) Depth excluding knobs GM338
59mm x 179mm x 198mm (25 - 40W)
(add 9mm for Volume Knob)
Weight GM338 1400 g
Sealing: Withstands rain testing per
MIL STD 810 C/D/E and IP54
Shock and Vibration: Protection provided via impact
resistant housing exceeding MIL STD
810-C/D/E
Dust, Salt & Fog: Protection provided via environment
resistant housing exceeding MIL STD
810 C/D/E
