39
English
Capacity Format Menu
Figure 11: Capacity Format Menu
Battery Capacity display options include:
Table 20: Battery Capacity Display Options
Representation Description
xxx0mAh Present Charge (State of Charge) in milliamp-hours.
yyy%
Present Charge relative to the Potential Capacity (when fully
charged), in percent. The maximum value is 100%.
%BAR The equivalent of yyy% represented in an eight-segment bar.
MN003555A01.book Page 39 Wednesday, February 14, 2018 2:40 PM
