Motorola Radius CM200

4-22 VHF 1–25 W Band 2 PCB 8488977U01 (rev. P9) / Schematics
C5064 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5065 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5066 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5067 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5068 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5069 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5070 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5071 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5072 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5073 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5074 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5075 NOT PLACED –
C5076 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5077 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5078 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5079 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5080 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5081 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5082 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5083 2113740F51
CAP CHIP REEL CL1 +/-30 100
C5084 2113740F51
CAP CHIP REEL CL1 +/
-30 100
C5085 2113741A53 CAP CHIP CL2 X7R REEL 22000
C5086 2113741A53 CAP CHIP CL2 X7R REEL 22000
C5087 2113740F53
CAP CHIP REEL CL1 +/-30 120
C5088 2113740F49
CAP CHIP REEL CL1 +/
-30 82
C5089 2113740F49
CAP CHIP REEL CL1 +/-30 82
C5090 2113740F49
CAP CHIP REEL CL1 +/
-30 82
C5091 2113740F49
CAP CHIP REEL CL1 +/-30 82
C5092 2113740F59
CAP CHIP REEL CL1 +/
-30 220
C5094 2113740F59
CAP CHIP REEL CL1 +/-30 220
C5095 2113740F59
CAP CHIP REEL CL1 +/
-30 220
Circuit
Ref.
Motorola
Part No.
Description
C5096 2113740F59
CAP CHIP REEL CL1 +/-30 220
C5097 2113740F59
CAP CHIP REEL CL1 +/
-30 220
C5098 2113740F59
CAP CHIP REEL CL1 +/-30 220
C5099 2113740F59
CAP CHIP REEL CL1 +/
-30 220
C5100 2113740F59
CAP CHIP REEL CL1 +/-30 220
C5101 2113741F25 CAP CHIP CL2 X7R REEL 1000
(Not used in GM3188/GM3189)
C5102 2113743E20 CAP CHIP. 10 UF 10%
(Not used in GM3188/GM3189)
C5103 2113743K15 CER CHIP CAP .100UF
(Not used in GM3188/GM3189)
C5104 NOT PLACED –
C5110 2113 741F 25 C AP CH IP CL2 X7R REEL 1000
C5111 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5113 NOT PLACED –
C5114 2113743F16
CAP CHIP 1.0UF 16V+80-20%
C5115 NOT PLACED –
C5116 NOT PLACED –
C5117 NOT PLACED –
C5118 2113743E20 CAP CHIP. 10 UF 10%
C5119 2113 743H 14
CAP CHIP 10.0 UF 16V +80-20%
C5120 NOT PLACED –
C5121 2113741F25 CAP CHIP CL2 X7R REEL 1000
C602 2113741F25 CAP CHIP CL2 X7R REEL 1000
C603 2113741F25 CAP CHIP CL2 X7R REEL 1000
C604 2113741F25 CAP CHIP CL2 X7R REEL 1000
C605 2113741F25 CAP CHIP CL2 X7R REEL 1000
C606 2113741F25 CAP CHIP CL2 X7R REEL 1000
C607 2113741F25 CAP CHIP CL2 X7R REEL 1000
C608 NOT PLACED –
C609 NOT PLACED –
C610 2113741F25 CAP CHIP CL2 X7R REEL 1000
C611 2113741F25 CAP CHIP CL2 X7R REEL 1000
Circuit
Ref.
Motorola
Part No.
Description
C612 2113741F25 CAP CHIP CL2 X7R REEL 1000
C613 2113741F25 CAP CHIP CL2 X7R REEL 1000
C614 2113741F25 CAP CHIP CL2 X7R REEL 1000
C615 2113741F25 CAP CHIP CL2 X7R REEL 1000
C616 2113741F25 CAP CHIP CL2 X7R REEL 1000
C617 2113741F25 CAP CHIP CL2 X7R REEL 1000
C618 2113741F25 CAP CHIP CL2 X7R REEL 1000
C619 NOT PLACED –
C620 2113741F25 CAP CHIP CL2 X7R REEL 1000
C621 2113741F25 CAP CHIP CL2 X7R REEL 1000
C622 2113741F25 CAP CHIP CL2 X7R REEL 1000
C623 2113741F25 CAP CHIP CL2 X7R REEL 1000
C624 2113741F25 CAP CHIP CL2 X7R REEL 1000
C625 2113741F25 CAP CHIP CL2 X7R REEL 1000
C626 2113741F25 CAP CHIP CL2 X7R REEL 1000
C627 2113741F25 CAP CHIP CL2 X7R REEL 1000
C628 2113741F25 CAP CHIP CL2 X7R REEL 1000
C629 2113741F25 CAP CHIP CL2 X7R REEL 1000
C630 2113741F25 CAP CHIP CL2 X7R REEL 1000
C631 2113741F25 CAP CHIP CL2 X7R REEL 1000
C632 2113741F25 CAP CHIP CL2 X7R REEL 1000
C633 2113741F25 CAP CHIP CL2 X7R REEL 1000
C662 2113741F25 CAP CHIP CL2 X7R REEL 1000
C678 2113741M69 CAP CHIP CLS2 100000 PF 20V
10
CR300 4880154K03 SOT MMBD353 RH DIODE
DUAL SCHT
CR301 4880154K03 SOT MMBD353 RH DIODE
DUAL SCHT
D100 NOT PLACED –
D101 4813833C02 DIODE DUAL 70V ‘5B’ COMM
CATH
D102 4813833C02 DIODE DUAL 70V ‘5B’ COMM
CATH
Circuit
Ref.
Motorola
Part No.
Description
D103 4802482J02 PIN DIODE SMD
D104 4802482J02 PIN DIODE SMD
D105 4805218N57 DIODE DUAL
D106 4805218N57 DIODE DUAL
D107 4805218N57 DIODE DUAL
D108 4805218N57 DIODE DUAL
D200 4802233J09
DIODE TRIPLE SOT25
-RH
D201 4802233J09
DIODE TRIPLE SOT25-RH
D202 4862824C03 DIODE VARACTOR
D203 4805649Q13 DIODE VCTR ISV 228
D204 4805649Q13 DIODE VCTR ISV 228
D205 4862824C01 DIODE VARACTOR
D301 4802245J97 Band Switchind Diode, Rohm
DAN
D302 4802245J97 Band Switchind Diode, Rohm
DAN
D303 4802245J97 Band Switchind Diode, Rohm
DAN
D304 4802245J97 Band Switchind Diode, Rohm
DAN
D305 4880142L01 SOT MMBV109 RH
D400 4813833C07 DIODE DUAL 100V ‘5C’ SERIES
D401 4813833C02 DIODE DUAL 70V ‘5B’ COMM
CATH
D402 4809948D42
DIODE SCHOTTKY RB751V-40
D500 4813833C02 DIODE DUAL 70V ‘5B’ COMM
CATH
D501 NOT PLACED –
D502 4813825A23 DIODE, DISCRETE SPECIALS
VAR&P
D511 4813833C02 DIODE DUAL 70V ‘5B’ COMM
CATH
D513 4813833C02 DIODE DUAL 70V ‘5B’ COMM
CATH
FL300 9180022M11 XTAL FILTER 44.85MHZ
Circuit
Ref.
Motorola
Part No.
Description
