Motorola Radius CM200

3-4 TROUBLESHOOTING CHARTS
2.0 Troubleshooting Flow TX RF (No Output Power)
START
Key the radio
No
Yes
Yes
No
Tune the
PA_BIAS
Measure TP102
Is
TP102
< 1.8 Vdc?
Short TP110 to ground
and measure the
Output Power
Is
POUT
< 1 Watt
?
Replace
L108
End
