Motorola Radius CM200

VHF 1–25 W Band 2 PCB 8486672Z01 / Schematics 4-53
VR501 4813830A14 DIODE 5.1V 5% 225MW
MMBZ5231B_
VR502 NOT PLACED –
VR503 4813830G09 DIODE 3.3V 5% ‘CK’ 500MW
_4684
VR504 4813830G09 DIODE 3.3V 5% ‘CK’ 500MW
_4684
VR692 4813830A75 DIODE DUAL COM ANODE
VR693 4813830A77 DIODE DL ZENER TVS 33V 1.0A
VR694 4813830A75 DIODE DUAL COM ANODE
VR695 4813830A77 DIODE DL ZENER TVS 33V 1.0A
VR696 4813830A75 DIODE DUAL COM ANODE
VR697 4813830A75 DIODE DUAL COM ANODE
VR698 4813830A75 DIODE DUAL COM ANODE
VR699 4813830A75 DIODE DUAL COM ANODE
Y200 NOT PLACED –
Y201 4880114R06 CRYSTAL 16.8MHZ
Y300 9186145B02
CER.DISCR. CDBCA455CX36-
TC
Y301 4880606B09 2ND OSC XTAL 44.395 MHZ
Circuit
Ref.
Motorola
Part No.
Description
