Motorola T600 Series - Chapter 1: Radio Overview; Radio Display Icons; Radio Icon Descriptions

1.2
Radio Display
This chapter explains the icons on the display of the radio.
Figure 2: LED Icons and Indicators
1
2
3
4
5
6 7
8
9
10
11
12
1314
15
18 17 19
16
Table 2: Radio Icon Descriptions
Item Number Description
1 Mute
2 Easy Pairing
3 Scan
4 Roger Tone
5 Dual Channel Monitor
6 Lock
7 Keypad Tone
8 Sub Code
9 Frequency
10 VOX or iVOX
11 Silent Mode (Vibrate Alert)
12 Call Tone
13 Transmit and Receive
14 Low or High Power
15 Weather Alert
16 Battery
