General Functions V171
13 August 1, 2004
Liquid Crystal Display (LCD)
The LCD provides a 700 square millimeter multicolor backlit color display with user-
adjustable contrast settings for optimum readability in all light conditions as shown in Figure
2. The bit-map 98 x 67 pixel display includes up to 3 lines of text, 1 line of icons, and 1 line of
prompts.
Figure 2. LCD Icons
Icon Name Description
Y
Alert Type
shows the current selected alert profile. The default
alert setting is loud ring.
5
Signal Strength
shows the strength of your phone's connection with the
network.
+
GPRS Active
indicates that your phone is using a high-speed GPRS
network connection. GPRS allows faster data transfer
speeds. The indicator does not mean that you are in a
call; only that you are registered on the network via a
GPRS connection.
U
In use
indicates when a call is in progress, and when you
have a secure or insecure connection.
;
Roam
appears when your phone uses another network sys-
tem outside your home network.
(
Message
appears when you have a new voice or text message
waiting. Icon here can also indicate your text entry
mode, alpha, numeric, symbol and etc.
9
Battery Level
shows the amount of charge left in your battery. The
more bars visible, the greater the charge.
J
Line Selection
displays the current line you are using, depending on
the service provider.
10:59
Clock displays the real time.
M
Menu
indicates that you may press Main Menu to open the
system menu.
