10
RADIO OVERVIEW
On/Off/Volume Knob
Used to turn the radio ON or OFF and to adjust
the radio’s volume.
Channel Selector Knob
Used to switch the radio to different channels.
Accessory Connector
Used to connect compatible audio accessories.
Model Label
Indicates the model of the radio.
Microphone
Speak clearly into the microphone when
sending a message.
Antenna
For model XT460, the antenna is
non-removable.
LED Indicator
Used to give battery status, power-up status,
radio call information and scan status.
Front Buttons
• (Menu) Button
Gives access to set up features like VOX/iVOX
levels, etc.
It also allows you to move through all the
features while in Programming Mode.
• Programmable Button
Allows you to choose level or toggle options for
features the Menu is on.
Default set to generate current programmed
call tone.
63M03_A_BRCAN_en.book Page 10 Monday, November 19, 2018 10:16 AM
